BASEFRAME AND LEG ASSEMBLY
(CONTINUED)
FIGURE SEVEN
FIGURE SEVEN
CANTON
Step #11: Square the baseframe by using the carpenter’s
square or measuring the diagonal corners. The diagonal
measurements should not vary over 1/8”. With the tables
square, securely tighten all remaining hardware.
BRUNSWICK INSTALLATION MANUAL PAGE 5
