Brush Wolf 7201 - 6600 HF Parts List

— 23 — www.brushwolf.com
6600 HF Parts Diagram - High Flow
ITEM ITEM QTY PART NUMBER DESCRIPTION
1 1
15054
PLATE, ACCESS, 2 HOLE, 5.250 X 3.250 X 0.250
2 1
15067
GUARD, COUPLING, BW, STD
3 1
15110
ROD, RND, 0.375 X 65.000
4 1
15418
PLATE, STAUFF, 3 HOLE COVER, 1.25 X 5.875
5 2 15589 HOSE WHIP ASSEMBLY, -12 ORFS, FEMALE SWIVEL COUPLINGS, 0.750 MFG X 78.000
6 1 15753 HOSE WHIP ASSEMBLY, -6 ORFS, FEMALE SWIVEL COUPLINGS, 0.375 MFG X 78.000 HOSE
7 1
15704
ASSEMBLY, BLADE CARRIER, BW6600
8 1
15734
WELDMENT, FRAME, BW 6600
9 1
15053
COUPLING, HF, 1.500 MOTOR, 1.375 GB, 5.500
10 50
15068
CHAIN, 0.313, 5 LINK, PROOF COIL
11 1
15114
COUPLER, FEMALE, SIZE 16, 1 1/6-12, O-RING BOSS
12 1 15115
COUPLER, MALE, SIZE 16, 1 1/6-12, O-RING BOSS
13 1 15092
GEARBOX, 62HP, 1:1.46 RATIO
14 1 15125
BLOCK, CROSSOVER RELIEF MANIFOLD, 6K MOTOR, ALUMINUM
15 1 15745
DECAL KIT, BW 6600 HF
16 1 15149
MOTOR, 11.9 CU IN, SAE “CC” 4 BOLT, 0.750 DIA SPLIT FLANGE BO STAGGERED PORTS,
1.500 DIA X 1.625 KEYED SHAFT BW
17 1 15401
CLAMP, BODY, TWO PIECE, 30-30-18, THREE HOSE, BLACK
18 4 15405
ADAPTER, STRAIGHT, #12 MORF, #12 MORB
19 1 15408
ADAPTER, STRAIGHT, #6 MORFS, #8 MORB
20 1 15414
COUPLER, FLAT FACED, FEMALE, 3/4-16, O-RING BOSS
21 1 15737
ADAPTER, 45 DEG, #6 MORFS, #4 MORB
22 4 Hardware
BOLT, HH, 1/2-13 X 2 1/2 UNC, GRD 5, ZINC
23 1 15274*
BOLT, HH, 1/2-13 X 3, GRD 2, ZINC
24 1 Hardware
BOLT, HH, 1/2-13 X 3/4 UNC, GRD 5, ZINC
25 2 Hardware
BOLT, HH, 3/8-16 X 3, GRD 5, ZINC
26 4 Hardware
BOLT, HH, 5/16-18 X 3/4, GRD 5, ZINC
27 5 Hardware
NUT, NYLOCK, 1/2-13, ZINC
28 4 Hardware
NUT, NYLOCK, 3/4-10, ZINC
29 4 Hardware
NUT, NYLOCK, 3/8-16, ZINC
30 8 Hardware
SCREW_ CAP_SH_ 3_8-16X3 1_2 GRD8
31 2 Hardware
SET SCREW_CP_1_4-20X3_8 UNC
32 4 Hardware
WASHER, FLAT, 1/2, ZINC
33 4 Hardware
WASHER, FLAT, 3/8, ZINC
34 4 Hardware
WASHER, FLAT, 5/16, ZINC
35 2
Hardware
WASHER, SPRING LOCK, .500, ZINC
36 4
Hardware
WASHER, SPRING LOCK, 5/16, ZINC
37 4 15379 WASHER, NORD-LOCK, 0.750 X 1.210 OD, ZINC
38 4 15381 WASHER, NORD-LOCK, 0.500 X 1.000 OD, ZINC
*SHEAR BOLT
