Brush Wolf 7201 - 7201 Low Flow & Standard Parts List

— 29 — www.brushwolf.com
7201 Parts List - Low Flow & Standard
ITEM ITEM QTY PART NUMBER DESCRIPTION
1 1
15054
PLATE, ACCESS, 2 HOLE, 5.250 X 3.250 X 0.250
2 1
15067
GUARD, COUPLING, BW, STD
3 1
15317
WELDMENT FRAME BW 7201
4 1
15343
ASSEMBLY, BLADE CARRIER, BW 7201
5 1
15344
DECAL KIT, BW 7201
6 2 15597
HOSE WHIP ASSEMBLY, -8 ORFS, FEMALE SWIVEL MFG COUPLINGS, 0.750 X 78.000 HOSE
7 1 15078
COUPLER, FLAT FACED, FEMALE, 7/8-14 O-RING BOSS
8 1 15079
COUPLER , FLAT FACED, MALE, 7/8-14 O-RING BOSS
9 1 15092*
STANDARD FLOW BRUSH CUTTER - GEARBOX, 62HP, 1:1.46 RATIO
9 1 15093*
LOW FLOW BRUSH CUTTER - GEARBOX, 62HP, 1:1.93 RATIO
10 1 15123
COUPLING, STD, 1.250 MOTOR, 1.375 GB, 5.500
11 1 15248
CLAMP, BODY, TWO PIECE, 30MM, TWO HOSE
12 1 15249
COVER PLATE, CLAMP, 30MM, TWO HOSE
13 1 15748
MOTOR, 8.0 CU IN, SAE “A” 2 BOLT, 7/8-14 SAE O-RING PORTS, 1.250 DIA X 1.250 KEYED
SHAFT, 3500/750 RELIEF, EATON
14 4 15584
ADAPTER, STRAIGHT, #8 ORFS, #10 ORB
15 1 Hardware
BOLT, HH, 5/16-18 X 2 1/2, GRD 5, ZINC
16 4 Hardware
BOLT, HH, 5/16-18 X 3/4, GRD 5, ZINC
17 2 Hardware
BOLT, HH, 1/2-13 X 2 UNC, GRD 5, ZINC
18 1 15274**
BOLT, HH, 1/2-13 X 3, GRD 2, ZINC
19 4 Hardware
NUT, NYLOCK, 3/8-16, ZINC
20 3 Hardware
NUT, NYLOCK, 1/2-13, ZINC
21 4 Hardware
NUT, NYLOCK, 3/4-10, ZINC
22 2 Hardware
SET SCREW_CP_1_4-20X3_8 UNC
23 4 Hardware
WASHER, FLAT, 5/16, ZINC
24 4 Hardware
WASHER, FLAT, 3/8, ZINC
25 2 15381
WASHER, NORD-LOCK, 0.500 X 1.000 OD, ZINC
26 4
15379 WASHER, NORD-LOCK, 0.750 X 1.210 OD, ZINC
27 5 Hardware
WASHER, SPRING LOCK, 5/16, ZINC
28 1 Hardware
WASHER, SPRING LOCK, 3/8, ZINC
*DEPENDS ON THE MODEL OF BRUSH CUTTER
**SHEAR BOLT
