PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 569F120 (cont)
LEGEND
569F120/524A-C150 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 121.0 123.0 132.0 143.0 131.0 131.0 138.0 148.0 140.0 138.0 143.0 153.0
SHC 121.0 116.0 96.4 75.6 131.0 131.0 112.0 85.1 140.0 138.0 127.0 94.5
kW 8.00 8.03 8.14 8.29 8.12 8.12 8.21 8.36 8.24 8.22 8.28 8.42
85
TC 119.0 121.0 130.0 141.0 129.0 129.0 135.0 146.0 138.0 137.0 140.0 150.0
SHC 119.0 115.0 95.5 74.8 129.0 129.0 111.0 84.3 138.0 137.0 126.0 93.6
kW 8.45 8.48 8.59 8.74 8.58 8.58 8.67 8.82 8.70 8.68 8.73 8.88
95
TC 115.0 117.0 125.0 136.0 125.0 125.0 131.0 141.0 134.0 133.0 135.0 145.0
SHC 115.0 112.0 93.7 73.1 125.0 125.0 109.0 82.5 134.0 133.0 124.0 91.9
kW 9.35 9.37 9.50 9.66 9.49 9.49 9.57 9.73 9.62 9.60 9.64 9.80
100
TC 113.0 115.0 123.0 133.0 123.0 123.0 128.0 138.0 131.0 131.0 132.0 142.0
SHC 113.0 111.0 92.8 72.1 123.0 123.0 108.0 81.6 131.0 131.0 123.0 91.0
kW 9.86 9.87 10.0 10.20 10.00 9.99 10.10 10.20 10.10 10.10 10.10 10.30
105
TC 112.0 113.0 121.0 131.0 121.0 121.0 125.0 135.0 129.0 129.0 130.0 139.0
SHC 112.0 110.0 91.8 71.2 121.0 121.0 107.0 80.7 129.0 129.0 122.0 90.0
kW 10.40 10.40 10.50 10.70 10.50 10.50 10.60 10.80 10.60 10.60 10.70 10.80
115
TC 108.0 108.0 116.0 126.0 116.0 116.0 120.0 130.0 124.0 124.0 124.0 133.0
SHC 108.0 107.0 89.9 69.4 116.0 116.0 105.0 78.9 124.0 123.0 120.0 88.2
kW 11.40 11.40 11.50 11.70 11.50 11.50 11.60 11.80 11.70 11.70 11.70 11.90
569F120/524A-B150 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 114.0 117.0 126.0 137.0 124.0 124.0 131.0 142.0 132.0 130.0 136.0 146.0
SHC 114.0 109.0 91.1 71.7 124.0 124.0 105.0 80.0 132.0 130.0 118.0 88.2
kW 7.93 7.96 8.07 8.20 8.03 8.04 8.13 8.27 8.14 8.12 8.19 8.33
85
TC 113.0 115.0 124.0 134.0 122.0 122.0 129.0 139.0 130.0 129.0 133.0 144.0
SHC 113.0 108.0 90.2 70.8 122.0 122.0 104.0 79.2 130.0 129.0 117.0 87.4
kW 8.37 8.40 8.51 8.65 8.49 8.49 8.58 8.72 8.59 8.57 8.64 8.78
95
TC 109.0 111.0 120.0 130.0 118.0 118.0 124.0 135.0 126.0 125.0 129.0 139.0
SHC 109.0 106.0 88.5 69.2 118.0 118.0 102.0 77.6 126.0 125.0 115.0 85.8
kW 9.27 9.29 9.41 9.56 9.39 9.39 9.48 9.63 9.51 9.48 9.55 9.70
100
TC 107.0 109.0 117.0 127.0 116.0 116.0 122.0 132.0 124.0 123.0 126.0 136.0
SHC 107.0 105.0 87.6 68.3 116.0 116.0 101.0 76.7 124.0 123.0 114.0 84.9
kW 9.77 9.79 9.91 10.10 9.90 9.89 9.99 10.10 10.00 9.99 10.10 10.20
105
TC 106.0 107.0 115.0 125.0 114.0 114.0 119.0 129.0 122.0 121.0 124.0 133.0
SHC 106.0 103.0 86.7 67.4 114.0 114.0 100.0 75.8 122.0 121.0 113.0 84.0
kW 10.30 10.30 10.40 10.60 10.40 10.40 10.50 10.70 10.50 10.50 10.60 10.70
115
TC 102.0 103.0 110.0 120.0 110.0 110.0 114.0 124.0 118.0 117.0 118.0 128.0
SHC 102.0 101.0 84.8 65.7 110.0 110.0 98.1 74.1 118.0 117.0 111.0 82.3
kW 11.30 11.30 11.40 11.60 11.40 11.40 11.50 11.70 11.50 11.50 11.60 11.70
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
569D072-120, 576C120, 569F120
