52
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 566E240 (cont)
LEGEND
566E240/524A-C300 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
7,500 10,000 12,500
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 249.0 254.0 272.0 293.0 268.0 268.0 282.0 303.0 281.0 281.0 289.0 309.0
SHC 249.0 236.0 196.0 154.0 268.0 268.0 226.0 172.0 281.0 281.0 253.0 190.0
kW 18.30 18.50 19.20 19.90 19.00 19.00 19.50 20.30 19.50 19.50 19.80 20.50
85
TC 245.0 249.0 267.0 288.0 263.0 263.0 277.0 297.0 276.0 276.0 283.0 303.0
SHC 245.0 234.0 194.0 152.0 263.0 263.0 224.0 170.0 276.0 276.0 251.0 188.0
kW 19.10 19.20 19.90 20.70 19.80 19.80 20.30 21.00 20.20 20.20 20.50 21.30
95
TC 237.0 240.0 257.0 277.0 254.0 254.0 266.0 285.0 266.0 266.0 272.0 290.0
SHC 237.0 229.0 190.0 148.0 254.0 254.0 220.0 166.0 266.0 266.0 246.0 184.0
kW 20.70 20.80 21.40 22.20 21.30 21.30 21.80 22.60 21.80 21.80 22.00 22.80
100
TC 232.0 235.0 251.0 271.0 249.0 250.0 260.0 279.0 261.0 261.0 266.0 284.0
SHC 232.0 226.0 187.0 145.0 249.0 250.0 217.0 164.0 261.0 261.0 244.0 182.0
kW 21.50 21.60 22.20 23.00 22.20 22.10 22.60 23.40 22.60 22.60 22.80 23.60
105
TC 228.0 230.0 246.0 265.0 244.0 245.0 254.0 272.0 256.0 256.0 260.0 277.0
SHC 228.0 223.0 185.0 143.0 244.0 245.0 215.0 162.0 256.0 256.0 241.0 180.0
kW 22.30 22.40 23.00 23.80 23.00 23.00 23.40 24.20 23.50 23.40 23.60 24.40
115
TC 219.0 219.0 234.0 252.0 234.0 234.0 241.0 259.0 244.0 244.0 247.0 263.0
SHC 219.0 217.0 180.0 139.0 234.0 234.0 210.0 157.0 244.0 244.0 235.0 175.0
kW 24.10 24.10 24.70 25.50 24.70 24.70 25.00 25.80 25.20 25.20 25.30 26.00
566E240/524A-B300 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
7,500 10,000 12,500
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 236.0 242.0 260.0 280.0 254.0 254.0 269.0 290.0 266.0 266.0 276.0 296.0
SHC 236.0 223.0 185.0 146.0 254.0 252.0 212.0 162.0 266.0 266.0 236.0 178.0
kW 17.90 18.10 18.70 19.50 18.50 18.50 19.10 19.80 18.90 18.90 19.30 20.00
85
TC 233.0 238.0 256.0 275.0 250.0 250.0 265.0 285.0 262.0 262.0 271.0 290.0
SHC 233.0 221.0 184.0 144.0 250.0 249.0 210.0 161.0 262.0 262.0 234.0 176.0
kW 18.70 18.80 19.50 20.20 19.30 19.30 19.80 20.60 19.70 19.70 20.00 20.80
95
TC 225.0 229.0 246.0 265.0 242.0 242.0 255.0 273.0 253.0 253.0 260.0 279.0
SHC 225.0 216.0 179.0 140.0 242.0 242.0 206.0 157.0 253.0 253.0 230.0 172.0
kW 20.30 20.40 21.00 21.80 20.90 20.90 21.40 22.10 21.30 21.30 21.60 22.30
100
TC 221.0 225.0 241.0 260.0 237.0 237.0 249.0 268.0 248.0 248.0 255.0 273.0
SHC 221.0 214.0 178.0 138.0 237.0 237.0 204.0 155.0 248.0 248.0 227.0 170.0
kW 21.10 21.20 21.80 22.50 21.70 21.70 22.10 22.90 22.10 22.10 22.40 23.10
105
TC 217.0 220.0 236.0 254.0 233.0 233.0 243.0 262.0 243.0 243.0 249.0 266.0
SHC 217.0 211.0 175.0 136.0 233.0 233.0 202.0 153.0 243.0 243.0 225.0 168.0
kW 22.00 22.10 22.60 23.40 22.50 22.50 23.00 23.70 22.90 22.90 23.20 23.90
115
TC 209.0 211.0 225.0 242.0 223.0 223.0 232.0 249.0 233.0 233.0 237.0 253.0
SHC 209.0 206.0 171.0 132.0 223.0 223.0 197.0 148.0 233.0 233.0 219.0 164.0
kW 23.80 23.80 24.40 25.10 24.30 24.30 24.60 25.40 24.70 24.70 24.90 25.60
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
566D/E150-240
