Bryant 566D User Manual

51
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 566E240
LEGEND
566E240/524A-C240 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
6,000 8,000 10,000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 228.0 239.0 258.0 279.0 248.0 252.0 269.0 290.0 262.0 262.0 277.0 297.0
SHC 228.0 207.0 174.0 139.0 248.0 240.0 199.0 155.0 262.0 262.0 222.0 169.0
kW 17.60 18.00 18.70 19.40 18.30 18.40 19.10 19.80 18.80 18.80 19.30 20.10
85
TC 225.0 235.0 254.0 274.0 245.0 248.0 265.0 285.0 258.0 258.0 272.0 291.0
SHC 225.0 205.0 172.0 137.0 245.0 237.0 197.0 153.0 258.0 258.0 220.0 167.0
kW 18.40 18.70 19.40 20.10 19.10 19.20 19.80 20.60 19.60 19.60 20.10 20.80
95
TC 218.0 227.0 244.0 263.0 236.0 238.0 254.0 274.0 249.0 249.0 261.0 280.0
SHC 218.0 201.0 168.0 134.0 236.0 232.0 193.0 149.0 249.0 249.0 216.0 163.0
kW 20.00 20.30 21.00 21.70 20.70 20.70 21.30 22.10 21.10 21.10 21.60 22.40
100
TC 214.0 222.0 239.0 258.0 232.0 234.0 249.0 268.0 245.0 245.0 255.0 274.0
SHC 214.0 199.0 166.0 132.0 232.0 229.0 190.0 147.0 245.0 245.0 213.0 161.0
kW 20.90 21.10 21.70 22.50 21.50 21.50 22.10 22.90 22.00 22.00 22.40 23.10
105
TC 211.0 217.0 234.0 252.0 228.0 229.0 243.0 262.0 240.0 240.0 249.0 267.0
SHC 211.0 196.0 163.0 130.0 228.0 226.0 188.0 145.0 240.0 240.0 211.0 159.0
kW 21.70 22.00 22.60 23.30 22.40 22.40 22.90 23.70 22.80 22.80 23.20 23.90
115
TC 203.0 207.0 223.0 241.0 219.0 219.0 231.0 249.0 230.0 230.0 237.0 254.0
SHC 203.0 192.0 159.0 125.0 219.0 219.0 184.0 140.0 230.0 230.0 206.0 155.0
kW 23.50 23.70 24.30 25.00 24.10 24.10 24.60 25.40 24.60 24.60 24.90 25.60
566E240/524A-B240 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
6,000 8,000 10,000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 219.0 229.0 248.0 267.0 237.0 241.0 259.0 278.0 250.0 251.0 265.0 285.0
SHC 219.0 199.0 167.0 134.0 237.0 228.0 190.0 148.0 250.0 250.0 211.0 161.0
kW 17.30 17.70 18.30 19.00 17.90 18.10 18.70 19.40 18.40 18.40 18.90 19.60
85
TC 216.0 226.0 243.0 263.0 234.0 237.0 254.0 273.0 246.0 247.0 261.0 280.0
SHC 216.0 197.0 165.0 132.0 234.0 226.0 188.0 146.0 246.0 246.0 209.0 159.0
kW 18.10 18.40 19.00 19.70 18.70 18.80 19.40 20.10 19.10 19.10 19.70 20.40
95
TC 209.0 217.0 234.0 253.0 226.0 228.0 244.0 263.0 238.0 238.0 250.0 269.0
SHC 209.0 192.0 161.0 128.0 226.0 221.0 184.0 142.0 238.0 238.0 205.0 155.0
kW 19.70 20.00 20.60 21.30 20.30 20.40 20.90 21.70 20.70 20.70 21.20 21.90
100
TC 206.0 213.0 230.0 248.0 222.0 224.0 239.0 257.0 234.0 234.0 245.0 263.0
SHC 206.0 190.0 159.0 126.0 222.0 218.0 182.0 140.0 234.0 234.0 202.0 153.0
kW 20.60 20.80 21.40 22.10 21.10 21.20 21.70 22.50 21.50 21.50 22.00 22.70
105
TC 202.0 209.0 225.0 242.0 218.0 219.0 233.0 251.0 229.0 229.0 239.0 257.0
SHC 202.0 188.0 157.0 124.0 218.0 215.0 180.0 138.0 229.0 229.0 200.0 151.0
kW 21.40 21.70 22.20 22.90 22.00 22.00 22.60 23.30 22.40 22.40 22.80 23.50
115
TC 195.0 200.0 215.0 232.0 210.0 210.0 223.0 239.0 220.0 220.0 228.0 244.0
SHC 195.0 184.0 153.0 120.0 210.0 209.0 175.0 134.0 220.0 220.0 196.0 147.0
kW 23.30 23.40 24.00 24.60 23.80 23.80 24.30 25.00 24.20 24.20 24.50 25.20
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
566D/E150-240
