Bryant 566D User Manual

72
ELECTRICAL DATA
524A-B,C STANDARD MOTORS
See Legend and Notes on page 73.
UNIT
524A-B
524A-C
V*-PH-Hz
VOLTAGE
LIMITS
FAN MOTOR POWER SUPPLY
Hp (kW) FLA
Minimum Circuit
Amps
MOCP
072
208/230-1-60 187-253 1.3 (0.97) 7.6 9.5 15
208/230-3-60 187-253 2.4 (1.79) 5.2 6.5 15
460-3-60 414-506 2.4 (1.79) 2.6 3.3 15
575-3-60 518-632 1.0 (0.75) 1.4 1.8 15
090
208/230-1-60 187-253 2.4 (1.79) 11.0 13.8 20
208/230-3-60 187-253 2.4 (1.79) 5.2 6.5 15
460-3-60 414-506 2.4 (1.79) 2.6 3.3 15
575-3-60 518-632 2.0 (1.49) 2.3 2.9 15
120
208/230-3-60 187-253 2.4 (1.79) 5.2 6.5 15
460-3-60 414-506 2.4 (1.79) 2.6 3.3 15
575-3-60 518-632 2.0 (1.49) 2.3 2.9 15
150
208/230-3-60 187-253 2.9 (2.16) 7.5 9.4 15
460-3-60 414-506 2.9 (2.16) 3.4 4.3 15
575-3-60 518-632 3.0 (2.24) 3.8 4.8 15
180
208/230-3-60 187-253 3.7 (2.76) 10.2 12.8 20
460-3-60 414-506 3.7 (2.76) 4.8 6.0 15
575-3-60 518-632 3.0 (2.24) 3.8 4.8 15
240
208/230-3-60 187-253 5.0 (3.73) 14.6/12.8 18.3/16.0 30/25
460-3-60 414-506 5.0 (3.73) 6.4 8.0 15
575-3-60 518-632 5.0 (3.73) 5.1 6.4 15
300
208/230-3-60 187-253 7.5 (5.59) 21.5/19.4 26.9/24.3 45/40
460-3-60 414-506 7.5 (5.59) 9.7 12.1 20
575-3-60 518-632 7.5 (5.59) 7.8 9.8 15
50TFQ004-012
524A072-300
