PERFORMANCE DATA
CONDENSING UNIT RATINGS
LEGEND
566D150
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
25
TC 101.0 97.6 90.0 86.0 82.2 74.7
kW 8.56 8.90 9.55 9.85 10.20 10.70
SDT 94.6 99.4 109.0 114.0 119.0 129.0
30
TC 118.0 113.0 105.0 101.0 96.7 88.5
kW 8.80 9.17 9.90 10.20 10.60 11.20
SDT 96.6 101.0 111.0 116.0 121.0 131.0
35
TC 134.0 129.0 120.0 116.0 111.0 102.0
kW 9.03 9.44 10.20 10.60 11.00 11.70
SDT 98.6 103.0 113.0 117.0 122.0 132.0
40
TC 150.0 145.0 135.0 130.0 126.0 116.0
kW 9.26 9.71 10.60 11.00 11.40 12.20
SDT 101.0 105.0 115.0 119.0 124.0 134.0
45
TC 166.0 161.0 150.0 145.0 140.0 130.0
kW 9.50 9.98 10.90 11.40 11.80 12.70
SDT 103.0 107.0 116.0 121.0 126.0 135.0
50
TC 182.0 177.0 166.0 160.0 155.0 144.0
kW 9.73 10.30 11.30 11.70 12.20 13.10
SDT 105.0 109.0 118.0 123.0 127.0 136.0
566D180
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
25
TC 139.0 134.0 126.0 121.0 117.0 108.0
kW 12.30 12.70 13.60 14.00 14.40 15.10
SDT 99.5 104.0 114.0 118.0 123.0 133.0
30
TC 159.0 154.0 144.0 139.0 134.0 125.0
kW 12.90 13.40 14.30 14.70 15.20 16.00
SDT 102.0 107.0 116.0 121.0 125.0 135.0
35
TC 179.0 173.0 163.0 157.0 152.0 142.0
kW 13.50 14.00 15.00 15.50 16.00 16.90
SDT 105.0 109.0 119.0 123.0 128.0 137.0
40
TC 198.0 192.0 181.0 175.0 170.0 158.0
kW 14.00 14.60 15.70 16.30 16.80 17.80
SDT 108.0 112.0 121.0 125.0 130.0 139.0
45
TC 218.0 212.0 199.0 193.0 187.0 175.0
kW 14.60 15.20 16.50 17.00 17.60 18.70
SDT 110.0 115.0 124.0 128.0 132.0 141.0
50
TC 237.0 231.0 218.0 211.0 205.0 192.0
kW 15.20 15.90 17.20 17.80 18.40 19.60
SDT 113.0 117.0 126.0 130.0 135.0 144.0
566D240
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
25
TC 175.0 169.0 157.0 151.0 145.0 134.0
kW 16.30 16.80 17.70 18.20 18.60 19.40
SDT 104.0 108.0 117.0 122.0 126.0 135.0
30
TC 200.0 193.0 180.0 173.0 166.0 154.0
kW 17.20 17.80 18.80 19.30 19.80 20.70
SDT 107.0 111.0 120.0 125.0 129.0 138.0
35
TC 224.0 217.0 202.0 195.0 188.0 175.0
kW 18.20 18.80 19.90 20.50 21.00 22.00
SDT 110.0 115.0 123.0 128.0 132.0 141.0
40
TC 249.0 241.0 225.0 218.0 210.0 195.0
kW 19.10 19.80 21.00 21.60 22.20 23.30
SDT 114.0 118.0 126.0 131.0 135.0 144.0
45
TC 273.0 265.0 248.0 240.0 232.0 216.0
kW 20.10 20.80 22.10 22.70 23.40 24.60
SDT 117.0 121.0 129.0 134.0 138.0 146.0
50
TC 297.0 289.0 271.0 262.0 253.0 236.0
kW 21.00 21.80 23.20 23.90 24.60 25.90
SDT 120.0 124.0 132.0 137.0 141.0 149.0
kW—Compressor Power
SDT — Saturated Discharge Temperature at Compressor (F)
SST — Saturated Suction Temperature (F)
TC — Gross Cooling Capacity (1000 Btuh)
566E150
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
20
TC 102.0 99.1 93.2 90.3 87.3 81.1
kW 9.04 9.58 10.80 11.40 12.10 13.50
SDT 103.0 108.0 118.0 123.0 128.0 138.0
25
TC 114.0 111.0 105.0 102.0 98.8 92.2
kW 9.09 9.64 10.90 11.50 12.20 13.60
SDT 103.0 108.0 118.0 123.0 128.0 138.0
30
TC 127.0 124.0 117.0 114.0 110.0 103.0
kW 9.14 9.70 10.90 11.50 12.20 13.70
SDT 103.0 108.0 118.0 123.0 128.0 138.0
35
TC 140.0 137.0 130.0 126.0 123.0 115.0
kW 9.19 9.75 11.00 11.60 12.30 13.70
SDT 103.0 108.0 118.0 123.0 128.0 138.0
40
TC 155.0 151.0 144.0 140.0 136.0 128.0
kW 9.26 9.81 11.00 11.70 12.30 13.80
SDT 103.0 108.0 118.0 123.0 128.0 138.0
45
TC 170.0 166.0 158.0 154.0 150.0 141.0
kW 9.37 9.90 11.10 11.70 12.40 13.90
SDT 103.0 108.0 118.0 123.0 128.0 138.0
50
TC 186.0 182.0 173.0 169.0 164.0 155.0
kW 9.55 10.10 11.30 11.90 12.60 14.00
SDT 104.0 109.0 119.0 124.0 129.0 139.0
566E180
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
20
TC 141.0 137.0 129.0 124.0 120.0 110.0
kW 12.01 12.60 13.70 14.30 14.90 16.10
SDT 101.0 105.0 115.0 120.0 125.0 135.0
25
TC 156.0 152.0 143.0 138.0 133.0 123.0
kW 12.40 12.90 14.00 14.60 15.20 16.40
SDT 102.0 107.0 116.0 121.0 126.0 136.0
30
TC 171.0 166.0 157.0 152.0 147.0 136.0
kW 12.70 13.20 14.30 14.90 15.50 16.70
SDT 104.0 108.0 118.0 123.0 127.0 137.0
35
TC 187.0 182.0 172.0 166.0 161.0 150.0
kW 13.10 13.60 14.70 15.30 15.90 17.10
SDT 105.0 110.0 119.0 12.04 129.0 138.0
40
TC 203.0 198.0 187.0 181.0 176.0 164.0
kW 13.50 14.00 15.10 15.70 16.30 17.50
SDT 107.0 112.0 121.0 126.0 130.0 140.0
45
TC 221.0 215.0 204.0 198.0 192.0 179.0
kW 13.90 14.50 15.60 16.10 16.70 17.90
SDT 109.0 114.0 123.0 127.0 132.0 141.0
50
TC 239.0 233.0 221.0 215.0 208.0 195.0
kW 14.40 14.90 16.10 16.70 17.20 18.40
SDT 111.0 116.0 125.0 129.0 134.0 143.0
566E240
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
20
TC 184.0 179.0 170.0 165.0 160.0 148.0
kW 16.20 17.00 18.50 19.40 20.20 21.70
SDT 105.0 110.0 119.0 124.0 129.0 139.0
25
TC 202.0 197.0 186.0 181.0 176.0 163.0
kW 16.80 17.50 19.00 19.80 20.60 22.20
SDT 107.0 112.0 121.0 126.0 131.0 140.0
30
TC 220.0 214.0 203.0 197.0 191.0 179.0
kW 17.30 18.00 19.50 20.30 21.10 22.70
SDT 109.0 113.0 123.0 127.0 132.0 141.0
35
TC 239.0 233.0 220.0 214.0 208.0 194.0
kW 18.00 18.60 20.10 20.80 21.60 23.20
SDT 111.0 116.0 125.0 129.0 134.0 143.0
40
TC 259.0 253.0 239.0 232.0 225.0 211.0
kW 18.70 19.30 20.70 21.50 22.20 23.80
SDT 113.0 118.0 127.0 131.0 136.0 145.0
45
TC 280.0 273.0 259.0 252.0 244.0 229.0
kW 19.40 20.10 21.50 22.20 22.90 24.50
SDT 116.0 120.0 129.0 134.0 138.0 147.0
50
TC 302.0 295.0 280.0 272.0 264.0 247.0
kW 20.20 20.90 22.30 23.00 23.70 25.20
SDT 118.0 123.0 132.0 136.0 140.0 149.0
50TFQ004-012
566D/E150-240
