MODEL NUMBER NOMENCLATURE
524A P B 120 000 GC
524A — Fan Coil
Voltage
E — 460-3-60†
J — 208/230-1-60 (Sizes 072, 090 Only)
P — 208/230-3-60
T — 575-3-60
Coil Option
B — DX Cooling Coil With TXVs
C — DX High Capacity Cooling Coil With TXVs
Nominal Cooling (Tons)
072 — 6
090 — 7-1/2
120 — 10
150 — 12-1/2
180 — 15
240 — 20
300 — 25
Factory-Installed Options
GC — Unpainted, Standard Motor
and Standard Drive
HC — Unpainted, Standard Motor
and Medium-Static Drive
(not available for 300 sizes)
TC — Unpainted, Alternate Motor
and Medium-Static Drive
(300 size only)
YC — Unpainted, Alternate Motor
and High-Static Drive*
ED — Painted, Standard Motor
and Standard Drive
FD — Painted, Standard Motor
and Medium-Static Drive
(not available for 300 size)
RD — Painted, Alternate Motor
and Medium-Static Drive
(300 size only)
WD — Painted, Alternate Motor
and High-Static Drive*
Nominal Heating (Btuh)
000 – Not applicable (524A-B and 524A-C Cooling-Only Units)
LEGEND
*The YC and WD option codes for all 090 size units with 208/230-1-60 voltage designate standard motor and high-static drive.
†All 524A072-150 units with an “E” voltage designation are triple voltage (i.e., 208/230/460-3-60). Size 524A180 is also triple voltage in the “E” con-
figuration unless the alternate motor (YC or WD) option is used.
DX — Direct Expansion
TXV—Thermostatic Expansion Valve
