15
PERFORMANCE DATA
CONDENSING UNIT RATINGS
LEGEND
569D072
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
25
TC 53.6 52.3 49.4 48.0 46.5 43.6
kW 4.24 4.49 5.02 5.31 5.60 6.24
SDT 101.0 106.0 115.0 120.0 125.0 135.0
30
TC 59.1 57.6 54.6 53.0 51.5 48.3
kW 4.33 4.57 5.10 5.39 5.69 6.33
SDT 102.0 107.0 117.0 122.0 126.0 136.0
35
TC 64.9 63.3 60.1 58.4 56.7 53.4
kW 4.42 4.67 5.20 5.49 5.79 6.43
SDT 104.0 109.0 118.0 123.0 128.0 138.0
40
TC 71.0 69.3 65.8 64.1 62.3 58.7
kW 4.53 4.77 5.31 5.60 5.90 6.55
SDT 106.0 110.0 120.0 125.0 129.0 139.0
45
TC 77.4 75.6 71.9 70.1 68.2 64.3
kW 4.65 4.89 5.43 5.72 6.02 6.68
SDT 107.0 112.0 122.0 126.0 131.0 141.0
50
TC 84.2 82.3 78.4 76.4 74.3 70.2
kW 4.78 5.03 5.56 5.86 6.16 6.81
SDT 109.0 114.0 123.0 128.0 133.0 142.0
569D090
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
25
TC 73.9 71.7 67.0 64.6 62.1 57.0
kW 5.81 6.14 6.84 7.21 7.58 8.36
SDT 98.6 104.0 114.0 118.0 123.0 133.0
30
TC 82.0 79.7 74.9 72.4 69.9 64.7
kW 5.88 6.21 6.90 7.28 7.65 8.46
SDT 99.6 104.0 114.0 119.0 124.0 134.0
35
TC 90.4 88.0 83.0 80.4 77.8 72.4
kW 5.98 6.31 7.02 7.40 7.78 8.59
SDT 101.0 106.0 115.0 120.0 125.0 135.0
40
TC 99.2 96.7 91.4 88.7 85.9 80.3
kW 6.09 6.43 7.14 7.53 7.92 8.74
SDT 103.0 107.0 117.0 122.0 126.0 136.0
45
TC 109.0 106.0 100.0 97.4 94.5 88.6
kW 6.22 6.56 7.28 7.68 8.07 8.91
SDT 104.0 109.0 119.0 123.0 128.0 138.0
50
TC 118.0 116.0 110.0 107.0 104.0 97.2
kW 6.36 6.70 7.43 7.83 8.23 9.09
SDT 106.0 111.0 120.0 125.0 130.0 139.0
569D120
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
25
TC 102.0 99.3 93.8 90.9 88.1 81.9
kW 8.04 8.38 9.13 9.55 9.95 10.85
SDT 101.0 106.0 116.0 121.0 126.0 136.0
30
TC 112.0 109.0 103.0 99.8 96.7 90.3
kW 8.26 8.60 9.31 9.65 10.05 10.95
SDT 103.0 107.0 117.0 12.02 127.0 136.0
35
TC 122.0 119.0 113.0 109.0 106.0 99.0
kW 8.52 8.85 9.55 9.95 10.35 11.15
SDT 104.0 109.0 118.0 123.0 128.0 137.0
40
TC 133.0 130.0 123.0 119.0 115.0 108.0
kW 8.81 9.15 9.85 10.25 10.55 11.35
SDT 106.0 110.0 120.0 125.0 129.0 139.0
45
TC 144.0 141.0 133.0 130.0 126.0 118.0
kW 9.12 9.45 10.15 10.55 10.85 11.65
SDT 108.0 112.0 122.0 126.0 131.0 140.0
50
TC 156.0 152.0 145.0 141.0 137.0 128.0
kW 9.45 9.85 10.55 10.85 11.25 12.05
SDT 109.0 114.0 123.0 128.0 133.0 142.0
576C120
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
25
TC 89.0 85.1 77.4 73.6 69.7 62.2
kW 7.52 7.79 8.29 8.49 8.70 9.02
SDT 103.0 108.0 118.0 123.0 128.0 138.0
30
TC 101.0 96.6 88.5 84.4 80.3 72.2
kW 7.76 8.07 8.64 8.89 9.14 9.55
SDT 104.0 108.0 118.0 123.0 128.0 138.0
35
TC 113.0 109.0 100.0 95.8 91.5 83.0
kW 8.01 8.36 8.99 9.28 9.55 10.05
SDT 105.0 109.0 119.0 124.0 128.0 138.0
40
TC 125.0 121.0 112.0 107.0 103.0 94.1
kW 8.29 8.66 9.35 9.65 9.95 10.55
SDT 106.0 111.0 120.0 125.0 129.0 139.0
45
TC 138.0 133.0 124.0 119.0 115.0 106.0
kW 8.57 8.97 9.75 10.05 10.50 11.05
SDT 108.0 113.0 122.0 127.0 131.0 140.0
50
TC 152.0 147.0 137.0 132.0 127.0 117.0
kW 8.85 9.28 10.15 10.45 10.90 11.55
SDT 111.0 115.0 124.0 129.0 133.0 142.0
569F120
SST (F)
Air Temperature Entering Condenser (F)
80 85 95 100 105 115
25
TC 90.5 87.9 82.6 79.8 76.9 71.1
kW 7.75 8.17 9.05 9.52 10.00 11.00
SDT 100.0 105.0 115.0 120.0 125.0 135.0
30
TC 100.0 97.8 92.2 89.3 86.3 80.2
kW 7.79 8.21 9.09 9.57 10.10 11.10
SDT 101.0 106.0 116.0 120.0 125.0 135.0
35
TC 111.0 108.0 102.0 99.0 96.0 89.7
kW 7.89 8.30 9.18 9.66 10.10 11.20
SDT 102.0 107.0 116.0 121.0 126.0 136.0
40
TC 122.0 119.0 112.0 109.0 106.0 99.4
kW 8.01 8.42 9.31 9.79 10.30 11.30
SDT 104.0 108.0 118.0 123.0 127.0 137.0
45
TC 133.0 130.0 123.0 120.0 116.0 109.0
kW 8.15 8.57 9.46 9.95 10.40 11.50
SDT 105.0 110.0 120.0 124.0 129.0 138.0
50
TC 145.0 141.0 134.0 131.0 127.0 120.0
kW 8.30 8.72 9.63 10.10 10.60 11.70
SDT 107.0 112.0 121.0 126.0 131.0 140.0
kW—Compressor Power
SDT — Saturated Discharge Temperature at Compressor (F)
SST — Saturated Suction Temperature (F)
TC — Gross Cooling Capacity (1000 Btuh)
50TFQ004-012
569D072-120, 576C120, 569F120
