42
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 566D180
LEGEND
566D180/524A-C180 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
4500 6000 7500
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 167.0 177.0 192.0 209.0 183.0 187.0 202.0 219.0 194.0 195.0 208.0 225.0
SHC 167.0 152.0 128.0 104.0 183.0 175.0 146.0 115.0 194.0 193.0 163.0 125.0
kW 13.10 13.40 13.90 14.40 13.60 13.70 14.10 14.70 13.90 13.90 14.30 14.80
85
TC 165.0 174.0 189.0 205.0 180.0 184.0 198.0 214.0 191.0 192.0 204.0 220.0
SHC 165.0 150.0 127.0 102.0 180.0 174.0 145.0 113.0 191.0 191.0 161.0 124.0
kW 13.70 14.00 14.50 15.00 14.20 14.30 14.80 15.30 14.60 14.60 15.00 15.50
95
TC 160.0 167.0 182.0 197.0 174.0 177.0 190.0 206.0 185.0 185.0 196.0 211.0
SHC 160.0 147.0 123.0 99.3 174.0 170.0 141.0 110.0 185.0 185.0 158.0 120.0
kW 14.90 15.20 15.70 16.40 15.50 15.60 16.10 16.70 15.90 15.90 16.30 16.90
100
TC 157.0 164.0 178.0 193.0 171.0 173.0 186.0 202.0 181.0 181.0 191.0 207.0
SHC 157.0 145.0 122.0 97.8 171.0 168.0 140.0 109.0 181.0 181.0 156.0 119.0
kW 15.50 15.80 16.40 17.00 16.10 16.20 16.70 17.40 16.50 16.50 17.00 17.60
105
TC 154.0 160.0 174.0 189.0 168.0 169.0 182.0 197.0 178.0 178.0 187.0 202.0
SHC 154.0 144.0 120.0 96.3 168.0 165.0 138.0 107.0 178.0 178.0 154.0 117.0
kW 16.00 16.30 17.00 17.70 16.70 16.80 17.40 18.10 17.20 17.20 17.60 18.30
115
TC 148.0 153.0 166.0 181.0 162.0 162.0 174.0 188.0 171.0 171.0 178.0 193.0
SHC 148.0 140.0 117.0 93.2 162.0 161.0 135.0 104.0 171.0 171.0 151.0 114.0
kW 17.30 17.50 18.20 19.00 18.00 18.00 18.60 19.40 18.50 18.50 18.90 19.70
566D180/524A-B180 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
4500 6000 7500
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 165.0 175.0 190.0 207.0 180.0 185.0 200.0 217.0 191.0 193.0 206.0 223.0
SHC 165.0 149.0 126.0 102.0 180.0 172.0 143.0 113.0 191.0 190.0 159.0 123.0
kW 13.00 13.30 13.80 14.30 13.50 13.60 14.10 14.60 13.80 13.90 14.30 14.80
85
TC 162.0 171.0 187.0 203.0 177.0 181.0 196.0 213.0 188.0 189.0 202.0 218.0
SHC 162.0 148.0 125.0 101.0 177.0 170.0 142.0 112.0 188.0 187.0 158.0 121.0
kW 13.60 13.90 14.40 15.00 14.10 14.20 14.70 15.30 14.50 14.50 14.90 15.50
95
TC 157.0 165.0 179.0 195.0 171.0 174.0 188.0 204.0 182.0 182.0 193.0 209.0
SHC 157.0 144.0 121.0 97.9 171.0 166.0 139.0 108.0 182.0 181.0 154.0 118.0
kW 14.80 15.10 15.70 16.30 15.30 15.50 16.00 16.60 15.80 15.80 16.20 16.90
100
TC 154.0 161.0 176.0 191.0 168.0 170.0 184.0 199.0 178.0 178.0 189.0 205.0
SHC 154.0 143.0 120.0 96.3 168.0 164.0 137.0 107.0 178.0 178.0 153.0 117.0
kW 15.30 15.70 16.30 17.00 16.00 16.10 16.70 17.30 16.40 16.40 16.90 17.50
105
TC 151.0 158.0 172.0 187.0 165.0 167.0 180.0 195.0 175.0 175.0 185.0 200.0
SHC 151.0 141.0 118.0 94.8 165.0 162.0 135.0 105.0 175.0 175.0 151.0 115.0
kW 15.90 16.20 16.90 17.60 16.60 16.70 17.30 18.00 17.00 17.00 17.50 18.20
115
TC 146.0 151.0 164.0 179.0 159.0 160.0 171.0 186.0 168.0 168.0 176.0 191.0
SHC 146.0 137.0 115.0 91.7 159.0 157.0 132.0 102.0 168.0 168.0 147.0 112.0
kW 17.10 17.40 18.10 18.90 17.80 17.90 18.50 19.30 18.30 18.30 18.80 19.50
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
566D/E150-240
