ELECTRICAL DATA (cont)
ELECTRIC HEATER DATA
See Legend and Notes on page 75.
HEATER PART NO. UNIT V-PH-Hz
FAN M OTOR
ELECTRIC HEATER(S)
MCA* MOCP*Nominal
Capacity (kW)
Actual Capacity (kW)
FLA
Hp kW FLA Stage 1 Stage 2 Total
CAELHEAT001A00
524A-B072-120
524A-C072-120
208-3-60
1.3† 0.97 7.6 5 3.8 — 3.8 10.4 22.5 25
2.4† 1.79 11.0 5 3.8 — 3.8 10.4 26.8 35
2.4 1.79 5.2 5 3.8 — 3.8 10.4 19.5 20
2.9 2.16 7.5 5 3.8 — 3.8 10.4 22.4 25
3.7 2.76 10.2 5 3.8 — 3.8 10.4 25.8 30
240-3-60
1.3† 0.97 7.6 5 5.0 — 5.0 12.0 24.5 25
2.4† 1.79 11.0 5 5.0 — 5.0 12.0 28.8 35
2.4 1.79 5.2 5 5.0 — 5.0 12.0 21.5 25
2.9 2.16 7.5 5 5.0 — 5.0 12.0 24.4 25
3.7 2.76 10.2 5 5.0 — 5.0 12.0 27.8 30
CAELHEAT002A00 480-3-60
2.4 1.79 2.6 5 5.0 — 5.0 6.00 10.8 15
2.9 2.16 3.4 5 5.0 — 5.0 6.00 11.8 15
3.7 2.76 4.8 5 5.0 — 5.0 6.00 13.5 15
CAELHEAT003A00 575-3-60
1.0 0.75 1.4 5 5.0 — 5.0 5.00 8.0 15
2.0 1.49 2.3 5 5.0 — 5.0 5.00 9.2 15
3.0 2.24 3.8 5 5.0 — 5.0 5.00 11.0 15
CAELHEAT004A00
208-3-60
1.3† 0.97 7.6 10 7.5 — 7.5 20.8 35.6 40
2.4† 1.79 11.0 10 7.5 — 7.5 20.8 39.8 40
2.4 1.79 5.2 10 7.5 — 7.5 20.8 32.6 35
2.9 2.16 7.5 10 7.5 — 7.5 20.8 35.4 40
3.7 2.76 10.2 10 7.5 — 7.5 20.8 38.8 40
240-3-60
1.3† 0.97 7.6 10 10.0 — 10.0 24.1 39.6 40
2.4† 1.79 11.0 10 10.0 — 10.0 24.1 43.8 50
2.4 1.79 5.2 10 10.0 — 10.0 24.1 36.6 40
2.9 2.16 7.5 10 10.0 — 10.0 24.1 39.4 40
3.7 2.76 10.2 10 10.0 — 10.0 24.1 42.8 50
CAELHEAT005A00 480-3-60
2.4 1.79 2.6 10 10.0 — 10.0 12.0 18.3 20
2.9 2.16 3.4 10 10.0 — 10.0 12.0 19.3 20
3.7 2.76 4.8 10 10.0 — 10.0 12.0 21.0 25
CAELHEAT006A00 575-3-60
1.0 0.75 1.4 10 10.0 — 10.0 10.0 14.3 15
2.0 1.49 2.3 10 10.0 — 10.0 10.0 15.4 20
3.0 2.24 3.8 10 10.0 — 10.0 10.0 17.3 20
CAELHEAT007A00
208-3-60
1.3† 0.97 7.6 15 11.3 — 11.3 31.3 48.6 50
2.4† 1.79 11.0 15 11.3 — 11.3 31.3 52.9 60
2.4 1.79 5.2 15 11.3 — 11.3 31.3 45.6 50
2.9 2.16 7.5 15 11.3 — 11.3 31.3 48.5 50
3.7 2.76 10.2 15 11.3 — 11.3 31.3 51.9 60
240-3-60
1.3† 0.97 7.6 15 15.0 — 15.0 36.1 54.6 60
2.4† 1.79 11.0 15 15.0 — 15.0 36.1 58.9 60
2.4 1.79 5.2 15 15.0 — 15.0 36.1 51.6 60
2.9 2.16 7.5 15 15.0 — 15.0 36.1 54.5 60
3.7 2.76 10.2 15 15.0 — 15.0 36.1 57.9 60
CAELHEAT008A00 480-3-60
2.4 1.79 2.6 15 15.0 — 15.0 18.0 25.8 30
2.9 2.16 3.4 15 15.0 — 15.0 18.0 26.8 30
3.7 2.76 4.8 15 15.0 — 15.0 18.0 28.6 30
CAELHEAT009A00 575-3-60
1.0 0.75 1.4 15 15.0 — 15.0 15.1 20.6 25
2.0 1.49 2.3 15 15.0 — 15.0 15.1 21.7 25
3.0 2.24 3.8 15 15.0 — 15.0 15.1 23.6 25
50TFQ004-012
524A072-300
