Bryant 566D - Page 76

76
ELECTRICAL DATA (cont)
ELECTRIC HEATER DATA (cont)
See Legend and Notes on page 77.
HEATER PART NO. UNIT V-PH-Hz
FAN MOTOR
ELECTRIC HEATER(S)
MCA* MOCP*
Nominal
Capacity (kW)
Actual Capacity (kW)
FLA
Hp kW FLA Stage 1 Stage 2 Total
CAELHEAT016A00
524A-B150-240
524A-C150-240
208-3-60
2.9 2.16 7.5 10 7.5 — 7.5 20.8 35.4 40
3.7 2.76 10.2 10 7.5 — 7.5 20.8 38.8 40
5.0 3.73 14.6 10 7.5 — 7.5 20.8 41.3 50
7.5 5.59 21.5 10 7.5 — 7.5 20.8 52.9 60
240-3-60
2.9 2.16 7.5 10 10.0 — 10.0 24.1 39.4 40
3.7 2.76 10.2 10 10.0 — 10.0 24.1 42.8 50
5.0 3.73 12.8 10 10.0 — 10.0 24.1 46.1 50
7.5 5.59 19.4 10 10.0 — 10.0 24.1 54.4 60
CAELHEAT017A00 480-3-60
2.9 2.16 3.4 10 10.0 — 10.0 12.0 19.3 20
3.7 2.76 4.8 10 10.0 — 10.0 12.0 21.0 25
5.0 3.73 6.4 10 10.0 — 10.0 12.0 23.0 25
7.5 5.59 9.7 10 10.0 — 10.0 12.0 27.2 30
CAELHEAT018A00 575-3-60
3.0 2.24 3.8 10 10.0 — 10.0 10.0 17.3 20
5.0 3.73 5.1 10 10.0 — 10.0 10.0 19.6 20
7.5 5.59 7.8 10 10.0 — 10.0 10.0 22.1 25
CAELHEAT019A00
208-3-60
2.9 2.16 7.5 20 14.9 — 14.9 41.5 51.2 70
3.7 2.76 10.2 20 14.9 — 14.9 41.5 64.6 70
5.0 3.73 14.6 20 14.9 — 14.9 41.5 70.1 80
7.5 5.59 21.5 20 14.9 — 14.9 41.5 78.7 80
240-3-60
2.9 2.16 7.5 20 19.9 — 19.9 47.9 69.2 70
3.7 2.76 10.2 20 19.9 — 19.9 47.9 72.6 80
5.0 3.73 12.8 20 19.9 — 19.9 47.9 75.8 80
7.5 5.59 19.4 20 19.9 — 19.9 47.9 84.1 80
CAELHEAT020A00 480-3-60
2.9 2.16 3.4 20 20.0 — 20.0 24.1 34.3 35
3.7 2.76 4.8 20 20.0 — 20.0 24.1 36.1 40
5.0 3.73 6.4 20 20.0 — 20.0 24.1 39.1 40
7.5 5.59 9.7 20 20.0 — 20.0 24.1 43.2 50
CAELHEAT021A00 575-3-60
3.0 2.24 3.8 20 20.0 — 20.0 20.1 29.9 30
5.0 3.73 5.1 20 20.0 — 20.0 20.1 31.5 35
7.5 5.59 7.8 20 20.0 — 20.0 20.1 34.9 35
CAELHEAT022A00
208-3-60
2.9 2.16 7.5 30 15.0 7.5 22.5 62.5 87.5 90
3.7 2.76 10.2 30 15.0 7.5 22.5 62.5 90.9 100
5.0 3.73 14.6 30 15.0 7.5 22.5 62.5 96.4 100
7.5 5.59 21.5 30 15.0 7.5 22.5 62.5 105.0 110
240-3-60
2.9 2.16 7.5 30 20.0 10.0 30.0 72.2 99.6 100
3.7 2.76 10.2 30 20.0 10.0 30.0 72.2 103.0 110
5.0 3.73 12.8 30 20.0 10.0 30.0 72.2 106.2 110
7.5 5.59 19.4 30 20.0 10.0 30.0 72.2 114.5 125
CAELHEAT023A00 480-3-60
2.9 2.16 3.4 30 20.0 10.0 30.0 36.1 49.4 50
3.7 2.76 4.8 30 20.0 10.0 30.0 36.1 51.1 60
5.0 3.73 6.4 30 20.0 10.0 30.0 36.1 53.1 60
7.5 5.59 9.7 30 20.0 10.0 30.0 36.1 57.2 60
CAELHEAT024A00 575-3-60
3.0 2.24 3.8 30 20.0 10.0 30.0 30.1 42.4 50
5.0 3.73 5.1 30 20.0 10.0 30.0 30.1 44.0 50
7.5 5.59 7.8 30 20.0 10.0 30.0 30.1 47.4 50
50TFQ004-012
524A072-300
