44
Table 8 -- Unit Wire/Fuse or HACR Breaker Sizing Data withFactoryInstalled2SpeedIndoorFanOption(cont)
UNIT
NOM.
V --- P h --- H z
IFM
TYPE
NO C.O. or UNPWR C.O. w/ PWRD C.O.
NO P.E. w/ P.E. (pwrd fr/ unit) NO P.E. w/ P.E. (pwrd fr/ unit)
MCA
MAX
FUSE or
HACR
BRKR
DISC. SIZE
MCA
MAX
FUSE or
HACR
BRKR
DISC. SIZE
MCA
MAX
FUSE or
HACR
BRKR
DISC. SIZE
MCA
MAX
FUSE or
HACR
BRKR
DISC. SIZE
FLA LRA FLA LRA FLA LRA FLA LRA
580J*28
208/230---3---60
STD 127.8/126.9 175/17 5 133/132 590 139.6/138.7 175/175 147/146 610 132.6/131.7 175/175 139/138 595 144.4/143.5 175/175 152 /151 615
MED 131.3 175 137 586 143.1 175 151 606 136.1 175 143 591 147.9 175 156 611
HIGH 142.7 175 150 665 154.5 200 164 685 147.5 175 156 670 159.3 200 169 690
4 6 0 --- 3 --- 6 0
STD 51.9 60 54 302 58.1 70 61 314 54.1 60 57 304 60.3 70 64 316
MED 54.1 60 57 300 60.3 70 64 312 56.3 70 59 302 62.5 80 66 31 4
HIGH 59.8 70 63 340 66.0 80 70 352 62.0 80 66 342 68.2 80 73 354
5 7 5 --- 3 --- 6 0
STD 41.7 50 44 244 46.5 60 49 252 43.4 50 46 246 48.2 60 51 254
MED 43.1 50 45 242 47.9 60 51 250 44.8 50 47 244 49.6 60 53 25 2
HIGH 45 50 47 269 49.8 60 53 277 46.7 60 49 271 51.5 60 55 27 9
580J*30
208/230---3---60
STD 141.5 175 148 702 153.3 200 162 72 2 146.3 175 154 707 158.1 200 16 7 727
MED 152.9 200 161 781 164.7 200 175 801 157.7 200 167 786 169.5 200 180 806
HIGH 154.8 200 163 812 166.6 200 177 832 159.6 200 169 817 171.4 200 182 837
4 6 0 --- 3 --- 6 0
STD 66.0 80 69 354 72.2 90 76 366 68.2 90 72 356 74.4 90 79 368
MED 71.7 90 76 394 77.9 100 83 406 73.9 90 78 396 80.1 100 85 408
HIGH 72.6 90 77 409 78.8 100 84 421 74.8 90 79 411 81.0 100 86 42 3
5 7 5 --- 3 --- 6 0
STD 56.0 70 59 264 60.8 80 64 272 57.7 70 61 266 62.5 80 66 274
MED 57.9 70 61 291 62.7 80 66 299 59.6 70 63 293 64.4 80 68 30 1
HIGH 60.8 80 64 302 65.6 80 70 310 62.5 80 66 304 67.3 80 72 312
See: “Legend and Notes for Tables 7 --- 9” on page 40.
4 8 T C --- 1 7 --- 3 0 --- V4 8 T C --- 1 7 --- 3 0 --- V4 8 T C --- 1 7 --- 3 0 --- V580J---17---30---V
