3
Rated Indoor Airflow (cfm)
The table to the right lists the rated indoor airflow used
for the AHRI efficiency rating for the units covered in this
document.
Model Number Full Load Airflow (cfm)
580J*17D/F/K/M 4900
580J*20D/F/K/M 6125
580J*24D/F/K/M 8000
580J*28D/F/K/M 8750
580J*30D/F 9750
Model
J - Puron
®
(R-410A) Refrigerant
Unit Type
580 - Gas Heat RTU
Packaging & 2-Speed Indoor Fan Motor
A = Standard Packaging
D = Standard Packaging & 2-speed indoor
fan motor
Cooling Tons (Vertical Air Flow Models Only)
17 = 15 tons
20 = 17.5 tons
24 = 20 tons
28 = 25 tons
30 = 27.5 tons
Heat Level Input
220 = 220,000
310 = 310,000
400 = 400,000
Indoor Fan Options (Vertical Air Flow Models Only)
1 = Standard Static/Vertical Supply, Return Air Flow
2 = Medium Static/Vertical Supply, Return Air Flow
3 = High Static/Vertical Supply, Return Air Flow
B =
Medium Static High Efficiency Motor/Vertical Supply,
Return Air Flow
C = High Static High Efficiency Motor/Vertical Supply,
Return Air Flow
Refrig. System/Gas Heat Options
D = Two stage compressor with Aluminum gas heat
exchanger
F = Two stage compressor with Stainless Steel gas heat
exchanger
K = Two Stage Cooling with Aluminum gas heat exchanger
and Perfect Humidity™ (only available on 17-28 sizes
with RTPF coil models)
M = Two Stage Cooling with Stainless Steel gas heat
exchanger and Perfect Humidity™ (only available on
17-28 sizes with RTPF coil models)
Novation Coil Only (Outdoor - Indoor - Hail Guard)
G = Al/Al - Al/Cu
H = Al/Al - Cu/Cu
J = Al/Al - E-coat Al/Cu
K = E-coat Al/Al - Al/Cu
L = E-coat Al/Al - E-coat Al/Cu
T = Al/Al - Al/Cu — Louvered Hail Guards
U = Al/Al - Cu/Cu — Louvered Hail Guards
V = Al/Al - E-coat Al/Cu — Louvered Hail Guards
W = E-coat Al/Al - Al/Cu — Louvered Hail Guards
X = E-coat Al/Al - E-coat Al/Cu — Louvered Hail Guards
Round Tube Plate Fin (RTPF) Coil Options
(Outdoor - Indoor - Hail Guard)
A = Al/Cu - Al/Cu
B = Precoat Al/Cu - Al/Cu
C = E-coat Al/Cu - Al/Cu
D = E-coat Al/Cu - E-coat Al/Cu
E = Cu/Cu - Al/Cu
F = Cu/Cu - Cu/Cu
M = Al/Cu - Al/Cu — Louvered Hail Guards
N = Precoat Al/Cu - Al/Cu — Louvered Hail Guards
P = E-coat Al/Cu - Al/Cu — Louvered Hail Guards
Q = E-coat Al/Cu - E-coat Al/Cu — Louvered Hail Guards
R = Cu/Cu - Al/Cu — Louvered Hail Guards
S = Cu/Cu - Cu/Cu — Louvered Hail Guards
Voltage
E = 460-3-60
P = 208/230-3-60
T = 575-3-60
Outdoor Air Options
A = None
B = Temperature Economizer w/ Barometric Relief
D = Temperature Economizer w/ PE (cent)
H =
Enthalpy Economizer w/ Barometric Relief
J =
Enthalpy Economizer w/ PE (cent)
P = Manual Outdoor Air Damper
Q = 2 Position Damper
U =
Temp Ultra Low Leak Economizer w/ Baro Relief
V = Temp Ultra Low Leak Economizer w/ PE (cent)
W =
Enthalpy Ultra Low Leak Economizer w/ Baro Relief
X = Enthalpy Ultra Low Leak Economizer w/ PE (cent)
Example:
Position:
580JE17D310G1A0AA
123456789
10
11 12 13 14 15 16 17
Factory Installed Options
0A = None
NOTE: See the 580J 15 to 27.5 ton Price Pages for
a complete list of factory installed options.
C13775
Fig. 1 -- 580J MRT Vertical Airflow Units Model Number Nomenclature (Example)
