Bryant 580J Series User Manual

27
C13764
Fig. 34 -- Typical Perfect Humidityt Dehumidification System Humidistat Wiring
Rc
Rh
W1
G
Y2
C
O/W2/B
Y1
OAT
RRS
SRTN
HUM
D1
D2
V+
Vg
X*
C
G
W2
W1
Y2
Y1
R
Edge Programable Thermostat
Unit CTB
THERMOSTAT
*Connection not required.
Perfect Humidity™ FIOP
C09501
Fig. 35 -- Typical Rooftop Unit with Perfect Humidity
Dehumidification System with Edge Programmable
Thermostat
2--Speed Indoor Fan Motor System with Variable
Frequency Drive (Factory
Option)
For details on operating 580J 2 stage cooling units equipped
with the factory installed Variable Frequency Drive (VFD)
option, refer to the Variable Frequency Drive (VFD)
Installation, Setup & Troubleshooting Supplement (Catalog
No. IIVFD--02, or later).
EconoMi$er X -- Ultra Low Leak Economizer
(Factory
Option)
For details on operating 580J 2 stage cooling units
equipped with a factory installed EconoMi$er X, refer to
the EconoMi$er X Installation, Setup & Troubleshooting
Supplement (Catalog No. IILLECON--02, or later).
580J-- 17-- 30--V
