DETAILED COOLING CAPACITIES* Continued
See notes on page 24.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
650AN036-D, E Outdoor Section With FX4(A,B)NF042 Indoor Section continued
1125
72 42.3 21.3 2.64 40.3 20.6 2.93 38.3 19.8 3.26 36.0 19.1 3.61 33.7 18.3 4.00 31.0 17.4 4.40
67 38.7 27.3 2.63 36.9 26.5 2.93 35.0 25.8 3.25 33.0 25.0 3.60 30.8 24.1 3.98 28.3 23.2 4.38
63†† 36.1 26.5 2.63 34.4 25.7 2.92 32.6 25.0 3.24 30.6 24.1 3.59 28.6 23.3 3.96 26.3 22.3 4.36
62 35.5 33.0 2.63 33.9 32.2 2.92 32.2 31.4 3.24 30.4 30.3 3.59 28.7 28.7 3.96 26.8 26.8 4.37
57 34.7 34.7 2.63 33.3 33.3 2.92 31.9 31.9 3.24 30.4 30.4 3.59 28.7 28.7 3.96 26.8 26.8 4.37
1250
72 42.7 22.1 2.69 40.7 21.4 2.98 38.6 20.6 3.31 36.3 19.9 3.66 33.9 19.0 4.05 31.2 18.1 4.46
67 39.2 28.6 2.68 37.3 27.9 2.98 35.4 27.1 3.30 33.2 26.3 3.65 31.0 25.4 4.03 28.5 24.5 4.43
63†† 36.6 27.8 2.68 34.8 27.0 2.97 32.9 26.2 3.29 31.0 25.4 3.64 28.8 24.5 4.01 26.5 23.5 4.41
62 36.1 34.8 2.68 34.5 33.9 2.97 32.8 32.8 3.29 31.2 31.2 3.64 29.4 29.4 4.02 27.4 27.4 4.42
57 35.7 35.7 2.68 34.3 34.3 2.97 32.8 32.8 3.29 31.2 31.2 3.64 29.4 29.4 4.02 27.4 27.4 4.42
1375
72 43.1 22.8 2.74 41.1 22.1 3.03 38.9 21.4 3.36 36.6 20.6 3.71 34.1 19.8 4.10 31.3 18.9 4.51
67 39.6 30.0 2.73 37.7 29.2 3.03 35.6 28.4 3.35 33.5 27.6 3.70 31.3 26.7 4.08 28.7 25.7 4.48
63†† 36.9 29.0 2.73 35.1 28.2 3.02 33.2 27.4 3.34 31.2 26.6 3.69 29.0 25.7 4.06 26.7 24.6 4.46
62 36.7 36.4 2.73 35.1 35.1 3.02 33.5 33.5 3.34 31.8 31.8 3.69 30.0 30.0 4.07 28.0 28.0 4.48
57 36.6 36.6 2.73 35.1 35.1 3.02 33.5 33.5 3.34 31.8 31.8 3.69 30.0 30.0 4.07 27.9 27.9 4.48
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CK3BA 042 1.00 0.93 CK5PA 042 0.99 0.93
048 1.01 0.92 048 0.99 0.90
CK5A/CK5BA 042 1.00 0.93 CK5PT 042 1.00 0.95
048 1.01 0.92 048 1.01 0.95
CK5A/CK5BT 042 1.00 0.93
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
048 1.01 0.92 CC5A/CD5AA 042 0.99 0.92
CK5A/CK5BW 048 1.01 0.92 CC5A/CD5AC 048 0.98 0.92
CK5PA 042 1.00 0.93 CC5A/CD5AW 042 0.98 0.92
048 1.01 0.92 048 0.99 0.92
CK5PT 042 1.00 0.93 CD5AA 048 1.00 0.92
048 1.01 0.92 CK3BA 042 0.99 0.96
CK5PW 048 1.01 0.92 048 1.00 0.96
COILS + 355MAV042040 VARIABLE-SPEED FURNACE CK5A/CK5BA 042 0.99 0.94
CC5A/CD5AA 042 0.99 0.93 048 0.99 0.94
CC5A/CD5AC 048 0.98 0.93 CK5A/CK5BT 042 0.99 0.96
CC5A/CD5AW 042 0.98 0.92 048 1.00 0.96
048 1.00 0.93 CK5PA 042 0.99 0.94
CD5AA 048 0.99 0.93 048 0.99 0.94
CK5A/CK5BA 042 0.99 0.91 CK5PT 042 0.99 0.96
CK5A/CK5BT 042 1.00 0.96 048 1.00 0.96
CK5A/CK5BW 048 1.01 0.96
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CK5PA 042 0.99 0.91 CC5A/CD5AA 042 0.99 0.92
CK5PT 042 1.00 0.96 CC5A/CD5AC 048 0.98 0.91
CK5PW 048 1.01 0.96 CC5A/CD5AW 042 0.98 0.92
COILS + 355MAV042060 VARIABLE-SPEED FURNACE 048 1.00 0.92
CC5A/CD5AA 042 0.99 0.92 CD5AA 048 1.00 0.92
CC5A/CD5AC 048 0.98 0.91 CK3BA 042 1.01 0.94
CD5AA 048 1.00 0.92 048 1.01 0.94
CK3BA 042 1.00 0.96 CK5A/CK5BA 042 1.01 0.92
CK5A/CK5BE 042 0.98 0.94 048 1.00 0.88
CK5PE 042 0.98 0.94 CK5A/CK5BT 042 1.01 0.94
COILS + 355MAV042080 VARIABLE-SPEED FURNACE 048 1.01 0.94
CC5A/CD5AA 042 0.99 0.93 CK5PA 042 1.01 0.92
CC5A/CD5AC 048 0.97 0.92 048 1.00 0.88
CC5A/CD5AW 042 0.98 0.93 CK5PT 042 1.01 0.94
048 0.99 0.93 048 1.01 0.94
CD5AA 048 0.99 0.93
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CK3BA 042 1.00 0.95 CC5A/CD5AA 042 0.99 0.92
048 1.01 0.95 CC5A/CD5AC 048 0.98 0.91
CK5A/CK5BA 042 0.99 0.93 CC5A/CD5AW 042 0.98 0.91
048 0.99 0.90 048 1.00 0.91
CK5A/CK5BT 042 1.00 0.95 CD5AA 048 1.00 0.91
048 1.01 0.95 CK5A/CK5BW 048 1.01 0.93
—— — CK5PW 048 1.01 0.93
