EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
650AN036-D, E Outdoor Section With FX4(A,B)NF042 Indoor Section
1125
72 42.3 21.3 2.64 40.3 20.6 2.93 38.3 19.8 3.26 36.0 19.1 3.61 33.7 18.3 4.00 31.0 17.4 4.40
67 38.7 27.3 2.63 36.9 26.5 2.93 35.0 25.8 3.25 33.0 25.0 3.60 30.8 24.1 3.98 28.3 23.2 4.38
63†† 36.1 26.5 2.63 34.4 25.7 2.92 32.6 25.0 3.24 30.6 24.1 3.59 28.6 23.3 3.96 26.3 22.3 4.36
62 35.5 33.0 2.63 33.9 32.2 2.92 32.2 31.4 3.24 30.4 30.3 3.59 28.7 28.7 3.96 26.8 26.8 4.37
57 34.7 34.7 2.63 33.3 33.3 2.92 31.9 31.9 3.24 30.4 30.4 3.59 28.7 28.7 3.96 26.8 26.8 4.37
1250
72 42.7 22.1 2.69 40.7 21.4 2.98 38.6 20.6 3.31 36.3 19.9 3.66 33.9 19.0 4.05 31.2 18.1 4.46
67 39.2 28.6 2.68 37.3 27.9 2.98 35.4 27.1 3.30 33.2 26.3 3.65 31.0 25.4 4.03 28.5 24.5 4.43
63†† 36.6 27.8 2.68 34.8 27.0 2.97 32.9 26.2 3.29 31.0 25.4 3.64 28.8 24.5 4.01 26.5 23.5 4.41
62 36.1 34.8 2.68 34.5 33.9 2.97 32.8 32.8 3.29 31.2 31.2 3.64 29.4 29.4 4.02 27.4 27.4 4.42
57 35.7 35.7 2.68 34.3 34.3 2.97 32.8 32.8 3.29 31.2 31.2 3.64 29.4 29.4 4.02 27.4 27.4 4.42
1375
72 43.1 22.8 2.74 41.1 22.1 3.03 38.9 21.4 3.36 36.6 20.6 3.71 34.1 19.8 4.10 31.3 18.9 4.51
67 39.6 30.0 2.73 37.7 29.2 3.03 35.6 28.4 3.35 33.5 27.6 3.70 31.3 26.7 4.08 28.7 25.7 4.48
63†† 36.9 29.0 2.73 35.1 28.2 3.02 33.2 27.4 3.34 31.2 26.6 3.69 29.0 25.7 4.06 26.7 24.6 4.46
62 36.7 36.4 2.73 35.1 35.1 3.02 33.5 33.5 3.34 31.8 31.8 3.69 30.0 30.0 4.07 28.0 28.0 4.48
57 36.6 36.6 2.73 35.1 35.1 3.02 33.5 33.5 3.34 31.8 31.8 3.69 30.0 30.0 4.07 27.9 27.9 4.48
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 042 0.99 1.02 CK5A/CK5BT 042 1.00 0.94
CC5A/CD5AC 048 0.98 0.98 048 1.01 0.94
CC5A/CD5AW 042 0.99 1.00 CK5PA 042 1.00 0.94
048 0.99 0.98 048 1.01 0.94
CD5AA 048 0.99 1.01 CK5PE 042 1.01 0.94
CE3AA 042 0.99 0.99 CK5PT 042 1.00 0.94
048 1.00 0.99 048 1.01 0.94
CF5AA 048 1.00 0.99
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE
CK3BA 042 0.98 1.00 CD5AA 048 1.01 0.93
048 0.99 0.99 CE3AA 048 1.00 0.93
CK5A/CK5BA 042 0.99 1.00 CK3BA 042 1.01 0.94
048 0.99 0.99 048 1.01 0.93
CK5A/CK5BE 042 0.97 0.97 CK5A/CK5BA 042 1.00 0.93
CK5A/CK5BT 042 0.99 1.00 048 1.01 0.93
048 0.99 0.99 CK5A/CK5BT 042 1.01 0.94
CK5A/CK5BW 048 0.99 0.99 048 1.01 0.93
CK5PA 042 0.99 1.00 CK5A/CK5BW 048 1.01 0.93
048 0.99 0.99 CK5PA 042 1.01 0.94
CK5PE 042 0.97 0.97 048 1.01 0.93
CK5PT 042 0.99 1.00 CK5PT 042 1.01 0.94
048 0.99 0.99 048 1.01 0.93
CK5PW 048 0.99 0.99 CK5PW 048 1.01 0.93
F(A,B)4BN(F,B,C) 042 0.99 1.01
COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE
FC4CN(F,B) 042 0.99 1.01 CC5A/CD5AW 048 1.00 0.93
FE4ANF 002 0.98 0.93 CD5AA 048 1.00 0.93
003 0.99 0.90 CE3AA 048 1.00 0.93
005 1.02 0.89 CK3BA 042 1.00 0.94
FK4DNF 003 0.99 0.90 048 1.01 0.94
005 1.02 0.89 CK5A/CK5BA 042 1.01 0.94
FV4BNF 002 0.98 0.93 048 1.01 0.94
003 0.99 0.90 CK5A/CK5BT 042 1.00 0.94
005 1.02 0.89 048 1.01 0.94
FX4BNF 042 1.00 1.00 CK5A/CK5BW 048 1.01 0.94
COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE CK5PA 042 1.00 0.94
CK5A/CK5BE 042 1.00 0.96 048 1.01 0.94
CK5PE 042 1.00 0.96 CK5PT 042 1.00 0.94
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE 048 1.01 0.94
CE3AA 048 1.00 0.94 CK5PW 048 1.01 0.94
CK3BA 042 1.00 0.94
COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE
048 1.01 0.94 CC5A/CD5AW 042 0.99 0.93
CK5A/CK5BA 042 1.00 0.94 048 1.01 0.93
048 1.01 0.94 CD5AA 048 1.01 0.93
CK5A/CK5BE 042 1.00 0.94 CE3AA 048 1.00 0.93
DETAILED COOLING CAPACITIES* Continued
