—22—
DETAILED COOLING CAPACITIES* Continued
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
650AN042-D, E Outdoor Section With FV4(A,B)NF003 Indoor Section continued
1225
72 48.5 24.4 2.95 46.4 23.6 3.32 44.1 22.8 3.72 41.7 21.9 4.17 39.0 21.0 4.65 36.1 20.0 5.17
67 44.6 30.9 2.91 42.6 30.1 3.28 40.5 29.2 3.68 38.3 28.3 4.12 35.8 27.4 4.61 33.2 26.3 5.12
63†† 41.7 30.1 2.89 39.8 29.3 3.25 37.8 28.4 3.65 35.7 27.5 4.09 33.4 26.5 4.57 31.0 25.5 5.09
62 41.0 37.2 2.88 39.2 36.3 3.24 37.3 35.3 3.65 35.3 34.3 4.09 33.2 33.0 4.57 31.1 31.1 5.09
57 39.7 39.7 2.87 38.2 38.2 3.24 36.7 36.7 3.64 35.0 35.0 4.08 33.1 33.1 4.57 31.1 31.1 5.09
1400
72 49.4 25.6 2.99 47.1 24.8 3.36 44.8 23.9 3.77 42.2 23.1 4.22 39.5 22.1 4.70 36.5 21.1 5.22
67 45.4 32.9 2.96 43.3 32.0 3.32 41.2 31.2 3.73 38.8 30.2 4.17 36.3 29.3 4.65 33.6 28.2 5.17
63†† 42.5 32.0 2.93 40.5 31.1 3.30 38.4 30.2 3.70 36.2 29.3 4.14 33.9 28.3 4.62 31.3 27.2 5.14
62 41.9 39.7 2.93 40.0 38.7 3.29 38.2 37.6 3.70 36.2 36.2 4.14 34.2 34.2 4.62 32.0 32.0 5.15
57 41.2 41.2 2.92 39.6 39.6 3.29 37.9 37.9 3.69 36.1 36.1 4.14 34.2 34.2 4.62 32.0 32.0 5.15
1575
72 50.0 26.7 3.04 47.7 25.9 3.41 45.3 25.1 3.81 42.7 24.2 4.26 39.9 23.2 4.74 36.8 22.2 5.26
67 46.0 34.7 3.00 43.9 33.9 3.37 41.6 33.0 3.77 39.3 32.1 4.22 36.7 31.1 4.70 33.9 29.9 5.22
63†† 43.1 33.7 2.98 41.0 32.8 3.34 38.9 31.9 3.74 36.7 31.0 4.19 34.3 29.9 4.66 31.6 28.8 5.18
62 42.7 41.9 2.97 40.9 40.7 3.34 39.0 39.0 3.74 37.1 37.1 4.19 35.1 35.1 4.68 32.8 32.8 5.20
57 42.4 42.4 2.97 40.8 40.8 3.34 39.0 39.0 3.74 37.1 37.1 4.19 35.1 35.1 4.68 32.8 32.8 5.20
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
COILS + 355MAV042080 VARIABLE-SPEED FURNACE COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CC5A/CD5AC 048 0.96 1.00 CC5A/CD5AC 048 0.96 0.98
CC5A/CD5AW 048 0.98 1.00 CC5A/CD5AW 048 0.98 0.98
CD5AA 048 0.98 1.00 CD5AA 048 0.98 0.98
CK5A/CK5BA 048 0.99 1.00 CK3BA 048 0.99 0.98
CK5A/CK5BT 048 0.99 1.00 CK5A/CK5BA 048 0.99 0.98
CK5PA 048 0.99 1.00 CK5A/CK5BT 048 0.99 0.98
CK5PT 048 0.99 1.00 CK5A/CK5BW 048 0.99 1.01
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
CK5PA 048 0.99 0.98
CC5A/CD5AC 048 0.96 0.99 CK5PT 048 0.99 0.98
CC5A/CD5AW 048 0.98 0.99 CK5PW 048 0.99 1.01
CD5AA 048 0.98 0.99
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CK3BA 048 0.99 1.01 CC5A/CD5AC 048 0.96 0.98
CK5A/CK5BA 048 0.99 1.00 CC5A/CD5AW 048 0.99 0.98
CK5A/CK5BT 048 0.99 1.00 CD5AA 048 0.98 0.98
CK5PA 048 0.99 1.00 CK5A/CK5BW 048 0.99 0.98
CK5PT 048 0.99 1.00 CK5PW 048 0.99 0.98
See notes on page 24.
