DETAILED COOLING CAPACITIES* Continued
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
650AN048-D, E, F Outdoor Section With FV4(A,B)NF005 Indoor Section
1400
72 54.7 27.7 3.20 52.2 26.8 3.56 49.6 25.9 3.96 46.9 24.9 4.41 43.9 23.9 4.90 40.7 22.8 5.43
67 50.2 35.2 3.16 47.9 34.3 3.52 45.5 33.3 3.92 43.0 32.3 4.36 40.3 31.3 4.85 37.4 30.1 5.39
63†† 46.8 34.3 3.13 44.7 33.3 3.49 42.4 32.4 3.89 40.1 31.3 4.33 37.6 30.3 4.82 34.9 29.1 5.36
62 46.1 42.5 3.12 44.0 41.5 3.48 42.0 40.5 3.88 39.7 39.3 4.33 37.5 37.5 4.82 35.2 35.2 5.37
57 44.9 44.9 3.11 43.2 43.2 3.47 41.4 41.4 3.88 39.6 39.6 4.33 37.5 37.5 4.82 35.2 35.2 5.37
1600
72 55.6 29.1 3.26 53.0 28.1 3.62 50.3 27.2 4.02 47.4 26.2 4.47 44.4 25.2 4.96 41.1 24.1 5.49
67 51.1 37.5 3.22 48.7 36.6 3.58 46.2 35.6 3.98 43.6 34.6 4.42 40.8 33.5 4.91 37.8 32.3 5.45
63†† 47.7 36.5 3.19 45.4 35.5 3.55 43.1 34.5 3.95 40.7 33.5 4.39 38.1 32.4 4.88 35.3 31.2 5.42
62 47.1 45.5 3.18 45.1 44.4 3.54 42.9 42.9 3.95 41.0 41.0 4.39 38.8 38.8 4.89 36.3 36.3 5.43
57 46.7 46.7 3.18 44.8 44.8 3.54 42.9 42.9 3.94 40.9 40.9 4.39 38.8 38.8 4.89 36.4 36.4 5.43
1800
72 56.3 30.4 3.32 53.6 29.4 3.68 50.8 28.5 4.08 47.9 27.5 4.53 44.8 26.5 5.01 41.4 25.4 5.55
67 51.7 39.7 3.28 49.3 38.8 3.64 46.7 37.8 4.04 44.1 36.8 4.48 41.2 35.7 4.97 38.2 34.4 5.51
63†† 48.3 38.5 3.24 46.0 37.5 3.60 43.6 36.5 4.00 41.1 35.5 4.45 38.5 34.4 4.94 35.7 33.1 5.48
62 48.2 48.1 3.24 46.2 46.2 3.61 44.2 44.2 4.01 42.1 42.1 4.46 39.8 39.8 4.95 37.3 37.3 5.50
57 48.1 48.1 3.24 46.2 46.2 3.60 44.2 44.2 4.01 42.1 42.1 4.46 39.8 39.8 4.95 37.3 37.3 5.50
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 060 0.98 1.07 CK5PA 060 0.98 0.98
CC5A/CD5AW 060 0.98 1.05 CK5PT 060 0.98 0.98
CD5PX 060 0.98 1.03 CK5PX 060 1.00 0.99
CE3AA 060 1.00 1.07
COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE
CK3BA 060 0.99 1.07 CC5A/CD5AW 060 0.98 0.97
CK5A/CK5BA 060 0.99 1.07 CE3AA 060 0.99 0.98
CK5A/CK5BT 060 0.99 1.07 CK3BA 060 0.98 0.97
CK5A/CK5BX 060 1.00 1.06 CK5A/CK5BA 060 0.98 0.97
CK5PA 060 0.99 1.07 CK5A/CK5BT 060 0.98 0.97
CK5PT 060 0.99 1.07 CK5A/CK5BX 060 1.00 0.98
CK5PX 060 1.00 1.06 CK5PA 060 0.98 0.97
F(A,B)4BN(F,B,C) 060 0.98 1.11 CK5PT 060 0.98 0.97
FB4BNB 070 1.01 1.08 CK5PX 060 1.00 0.98
FC4CN(F,B) 060 0.98 1.11
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
FC4CNB 070 1.01 1.08 CC5A/CD5AA 060 0.95 1.00
FE4ANB 006 1.02 0.98 CC5A/CD5AW 048 0.95 1.00
FE4ANF 005 1.00 1.00 CK3BA 060 0.98 1.04
FK4DNB 006 1.02 0.98 CK5A/CK5BA 060 0.99 1.05
FK4DNF 005 1.00 1.00 CK5A/CK5BT 060 0.99 1.05
FV4BNB 006 1.02 0.98 CK5A/CK5BX 060 0.99 1.03
FV4BNF 005 1.00 1.00 CK5PA 060 0.99 1.05
FX4BNB 060 1.00 1.06 CK5PT 060 0.99 1.05
FX4BNF 048 0.99 1.07 CK5PX 060 0.99 1.03
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CE3AA 060 0.98 1.00 CC5A/CD5AA 060 0.95 0.99
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE
CC5A/CD5AW 048 0.95 1.00
CD5PX 060 0.99 0.98 CD5PX 060 0.98 1.00
CE3AA 060 0.99 0.99 CK3BA 060 0.99 1.02
CK3BA 060 0.98 0.98 CK5A/CK5BA 060 0.99 1.02
CK5A/CK5BA 060 0.98 0.98 CK5A/CK5BT 060 0.99 1.02
CK5A/CK5BT 060 0.98 0.98 CK5A/CK5BX 060 1.00 1.01
CK5A/CK5BX 060 1.00 0.98 CK5PA 060 0.99 1.02
CK5PA 060 0.98 0.98 CK5PT 060 0.99 1.02
CK5PT 060 0.98 0.98 CK5PX 060 1.00 1.01
CK5PX 060 1.00 0.98
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE
CC5A/CD5AA 060 0.95 0.99
CC5A/CD5AW 060 0.98 0.98 CC5A/CD5AW 048 0.95 0.99
CE3AA 060 0.99 0.99 CK5A/CK5BA 060 0.99 1.02
CK3BA 060 0.98 0.98 CK5A/CK5BT 060 0.99 1.02
CK5A/CK5BA 060 0.98 0.98 CK5A/CK5BX 060 1.00 1.01
CK5A/CK5BT 060 0.98 0.98 CK5PA 060 0.99 1.02
CK5A/CK5BX 060 1.00 0.99 CK5PT 060 0.99 1.02
—— — CK5PX 060 1.00 1.01
