—27—
HEAT PUMP HEATING PERFORMANCE Continued
See notes on page 32.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 27 37475767
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW†
650A036-D, E Outdoor Section With FX4(A,B)NF042 Indoor Section
65
1050 15.3 14.1 2.32 19.0 17.5 2.43 22.8 20.8 2.55 26.9 23.9 2.68 31.5 28.7 2.83 36.8 36.8 3.00 43.1 43.1 3.23 50.4 50.4 3.52
1275 15.8 14.5 2.37 19.5 17.9 2.47 23.3 21.2 2.57 27.4 24.4 2.69 32.1 29.2 2.82 37.5 37.5 2.98 44.0 44.0 3.18 51.1 51.1 3.40
1500 16.2 14.9 2.43 19.9 18.3 2.52 23.7 21.6 2.62 27.9 24.8 2.72 32.6 29.7 2.84 38.2 38.2 2.99 44.8 44.8 3.19 51.1 51.1 3.36
70
1050 14.9 13.7 2.42 18.6 17.1 2.54 22.5 20.6 2.68 26.6 23.6 2.82 31.1 28.3 2.97 36.3 36.3 3.15 42.4 42.4 3.38 49.6 49.6 3.68
1275 15.3 14.1 2.47 19.1 17.6 2.58 23.0 21.0 2.70 27.1 24.1 2.82 31.7 28.8 2.96 37.0 37.0 3.12 43.3 43.3 3.33 50.5 50.5 3.57
1500 15.7 14.5 2.53 19.6 18.0 2.63 23.4 21.3 2.74 27.5 24.5 2.85 32.2 29.3 2.98 37.6 37.6 3.13 44.1 44.1 3.33 50.9 50.9 3.54
75
1050 14.4 13.2 2.53 18.2 16.7 2.66 22.2 20.3 2.81 26.2 23.3 2.96 30.7 28.0 3.12 35.8 35.8 3.31 41.7 41.7 3.55 48.8 48.8 3.86
1275 14.9 13.7 2.58 18.7 17.2 2.70 22.7 20.7 2.83 26.8 23.8 2.96 31.3 28.5 3.10 36.5 36.5 3.27 42.7 42.7 3.49 49.9 49.9 3.77
1500 15.3 14.0 2.64 19.1 17.6 2.75 23.1 21.1 2.87 27.2 24.2 2.99 31.8 29.0 3.12 37.1 37.1 3.28 43.4 43.4 3.48 50.3 50.3 3.71
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Heating
Indoor
Section Size
Heating
Capacity Power Capacity Power
CC5A/CD5AA 042 0.99 1.05 CK5A/CK5BA 042 0.98 0.97
CC5A/CD5AC 048 0.98 1.03 048 0.98 0.95
CC5A/CD5AW 042 0.99 1.04 CK5A/CK5BE 042 0.98 0.96
048 0.97 0.97 CK5A/CK5BT 042 0.98 0.97
CD5AA 048 0.99 1.03 048 0.98 0.95
CE3AA 042 0.99 1.02 CK5PA 042 0.98 0.97
048 0.99 1.00 048 0.98 0.95
CF5AA 048 0.98 1.01 CK5PE 042 0.98 0.95
CK3BA 042 0.93 1.02 CK5PT 042 0.98 0.97
048 1.00 1.01 048 0.98 0.95
CK5A/CK5BA 042 0.99 1.02
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE
048 1.00 1.01 CD5AA 048 0.96 0.94
CK5A/CK5BE 042 0.92 1.05 CE3AA 048 0.98 0.96
CK5A/CK5BT 042 0.99 1.02 CK3BA 042 0.97 0.96
048 1.00 1.01 048 0.98 0.94
CK5A/CK5BW 048 1.00 1.01 CK5A/CK5BA 042 0.97 0.96
CK5PA 042 0.99 1.02 048 0.98 0.94
048 1.00 1.01 CK5A/CK5BT 042 0.97 0.96
CK5PE 042 0.92 1.05 048 0.98 0.94
CK5PT 042 0.99 1.02 CK5A/CK5BW 048 0.98 0.94
048 1.00 1.01 CK5PA 042 0.97 0.96
CK5PW 048 1.00 1.01 048 0.98 0.95
F(A,B)4BN(F,B,C) 042 1.00 1.03 CK5PT 042 0.97 0.96
FC4CN(F,B) 042 1.00 1.03 048 0.98 0.94
FE4ANF 002 0.91 0.98 CK5PW 048 0.98 0.94
003 0.96 0.97
COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE
005 0.95 0.89 CC5A/CD5AW 048 0.96 0.94
FK4DNF 003 0.96 0.97 CD5AA 048 0.96 0.94
005 0.95 0.89 CE3AA 048 0.98 0.96
FV4BNF 002 0.91 0.98 CK3BA 042 0.97 0.96
003 0.96 0.97 048 0.98 0.95
005 0.95 0.89 CK5A/CK5BA 042 0.98 0.96
FX4BNF 042 1.00 1.00 048 0.98 0.95
COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE CK5A/CK5BT 042 0.97 0.96
CK5A/CK5BE 042 0.98 0.97 048 0.98 0.95
CK5PE 042 0.98 0.97 CK5A/CK5BW 048 0.98 0.95
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE CK5PA 042 0.97 0.96
CE3AA 048 0.98 0.97 048 0.98 0.95
CK3BA 042 0.98 0.97 CK5PT 042 0.98 0.96
048 0.98 0.95 048 0.98 0.95
