—28—
HEAT PUMP HEATING PERFORMANCE Continued
See notes on page 32.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 2737475767
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW†
650A036-D, E Outdoor Section With FX4(A,B)NF042 Indoor Section continued
65
1050 15.3 14.1 2.32 19.0 17.5 2.43 22.8 20.8 2.55 26.9 23.9 2.68 31.5 28.7 2.83 36.8 36.8 3.00 43.1 43.1 3.23 50.4 50.4 3.52
1275 15.8 14.5 2.37 19.5 17.9 2.47 23.3 21.2 2.57 27.4 24.4 2.69 32.1 29.2 2.82 37.5 37.5 2.98 44.0 44.0 3.18 51.1 51.1 3.40
1500 16.2 14.9 2.43 19.9 18.3 2.52 23.7 21.6 2.62 27.9 24.8 2.72 32.6 29.7 2.84 38.2 38.2 2.99 44.8 44.8 3.19 51.1 51.1 3.36
70
1050 14.9 13.7 2.42 18.6 17.1 2.54 22.5 20.6 2.68 26.6 23.6 2.82 31.1 28.3 2.97 36.3 36.3 3.15 42.4 42.4 3.38 49.6 49.6 3.68
1275 15.3 14.1 2.47 19.1 17.6 2.58 23.0 21.0 2.70 27.1 24.1 2.82 31.7 28.8 2.96 37.0 37.0 3.12 43.3 43.3 3.33 50.5 50.5 3.57
1500 15.7 14.5 2.53 19.6 18.0 2.63 23.4 21.3 2.74 27.5 24.5 2.85 32.2 29.3 2.98 37.6 37.6 3.13 44.1 44.1 3.33 50.9 50.9 3.54
75
1050 14.4 13.2 2.53 18.2 16.7 2.66 22.2 20.3 2.81 26.2 23.3 2.96 30.7 28.0 3.12 35.8 35.8 3.31 41.7 41.7 3.55 48.8 48.8 3.86
1275 14.9 13.7 2.58 18.7 17.2 2.70 22.7 20.7 2.83 26.8 23.8 2.96 31.3 28.5 3.10 36.5 36.5 3.27 42.7 42.7 3.49 49.9 49.9 3.77
1500 15.3 14.0 2.64 19.1 17.6 2.75 23.1 21.1 2.87 27.2 24.2 2.99 31.8 29.0 3.12 37.1 37.1 3.28 43.4 43.4 3.48 50.3 50.3 3.71
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Heating
Indoor
Section Size
Heating
Capacity Power Capacity Power
CK5PW 048 0.98 0.95 CK5A/CK5BT 042 0.92 0.97
COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE 048 0.92 0.94
CC5A/CD5AW 042 0.96 0.98 CK5PA 042 0.99 1.00
048 0.96 0.94 048 0.98 0.99
CD5AA 048 0.95 0.94 CK5PT 042 0.92 0.97
CE3AA 048 0.97 0.96 048 0.92 0.94
CK3BA 042 0.97 0.96
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
048 0.98 0.94 CC5A/CD5AA 042 0.96 0.97
CK5A/CK5BA 042 0.97 0.96 CC5A/CD5AC 048 0.95 0.99
048 0.98 0.94 CC5A/CD5AW 042 0.95 0.99
CK5A/CK5BT 042 0.97 0.96 048 0.97 0.95
048 0.98 0.94 CD5AA 048 0.96 0.94
CK5A/CK5BW 048 0.98 0.94 CK3BA 042 0.92 0.98
CK5PA 042 0.97 0.96 048 0.93 0.97
048 0.98 0.94 CK5A/CK5BA 042 1.00 1.01
CK5PT 042 0.97 0.95 048 1.01 1.00
048 0.98 0.94 CK5A/CK5BT 042 0.92 0.98
CK5PW 048 0.98 0.94 048 0.93 0.97
COILS + 355MAV042040 VARIABLE-SPEED FURNACE CK5PA 042 1.00 1.01
CC5A/CD5AA 042 0.96 0.98 048 1.01 1.00
CC5A/CD5AC 048 0.95 1.00 CK5PT 042 0.92 0.98
CC5A/CD5AW 042 0.95 0.99 048 0.93 0.97
048 0.97 0.96
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CD5AA 048 0.96 0.94 CC5A/CD5AA 042 0.96 0.97
CK5A/CK5BA 042 0.97 1.00 CC5A/CD5AC 048 0.95 0.99
CK5A/CK5BT 042 0.92 0.98 CC5A/CD5AW 042 0.95 0.98
CK5A/CK5BW 048 0.93 0.96 048 0.96 0.94
CK5PA 042 0.97 1.00 CD5AA 048 0.96 0.93
CK5PT 042 0.92 0.98 CK3BA 042 0.92 0.95
CK5PW 048 0.93 0.96 048 0.92 0.95
COILS + 355MAV042060 VARIABLE-SPEED FURNACE CK5A/CK5BA 042 0.99 0.98
CC5A/CD5AA 042 0.96 0.97 048 0.97 0.95
CC5A/CD5AC 048 0.95 0.99 CK5A/CK5BT 042 0.92 0.95
CD5AA 048 0.95 0.93 048 0.92 0.95
CK3BA 042 0.92 0.98 CK5PA 042 0.99 0.98
CK5A/CK5BE 042 0.91 0.96 048 0.97 0.95
CK5PE 042 0.91 0.96 CK5PT 042 0.92 0.95
COILS + 355MAV042080 VARIABLE-SPEED FURNACE 048 0.92 0.95
CC5A/CD5AA 042 0.96 0.98
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CC5A/CD5AC 048 0.95 1.00 CC5A/CD5AA 042 0.96 0.96
CC5A/CD5AW 042 0.95 0.99 CC5A/CD5AC 048 0.95 0.99
048 0.97 0.96 CC5A/CD5AW 042 0.95 0.98
CD5AA 048 0.96 0.95 048 0.95 0.93
CK3BA 042 0.92 0.97 CD5AA 048 0.95 0.93
048 0.92 0.94 CK5A/CK5BW 048 0.92 0.93
CK5A/CK5BA 042 0.99 1.00 CK5PW 048 0.92 0.93
048 0.98 0.99 — — —
