—29—
HEAT PUMP HEATING PERFORMANCE Continued
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 27 37475767
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW†
650A042-D, E Outdoor Section With FV4(A,B)NF003 Indoor Section
65
1225 17.3 15.9 2.61 21.5 19.7 2.74 25.6 23.4 2.86 30.0 26.6 2.99 35.1 32.0 3.15 41.1 41.1 3.35 48.2 48.2 3.61 56.4 56.4 3.96
1400 17.6 16.1 2.61 21.7 20.0 2.73 25.9 23.6 2.84 30.2 26.9 2.95 35.5 32.3 3.09 41.6 41.6 3.28 48.8 48.8 3.53 57.2 57.2 3.86
1575 17.8 16.4 2.62 21.9 20.2 2.73 26.1 23.8 2.83 30.5 27.1 2.93 35.8 32.6 3.06 42.0 42.0 3.24 49.4 49.4 3.47 57.1 57.1 3.72
70
1225 16.8 15.4 2.74 21.1 19.4 2.88 25.4 23.1 3.03 29.6 26.3 3.16 34.7 31.6 3.33 40.5 40.5 3.53 47.5 47.5 3.81 55.5 55.5 4.17
1400 17.1 15.7 2.74 21.3 19.6 2.87 25.6 23.3 3.00 29.9 26.6 3.12 35.0 31.9 3.27 41.0 41.0 3.46 48.1 48.1 3.72 56.3 56.3 4.06
1575 17.3 15.9 2.75 21.6 19.8 2.87 25.8 23.5 2.99 30.2 26.8 3.10 35.3 32.2 3.24 41.4 41.4 3.41 48.6 48.6 3.66 56.9 56.9 4.00
75
1225 16.2 14.9 2.88 20.6 18.9 3.03 25.1 22.8 3.19 29.3 26.0 3.34 34.3 31.2 3.51 39.9 39.9 3.73 46.7 46.7 4.01 54.6 54.6 4.39
1400 16.5 15.2 2.88 20.9 19.2 3.02 25.3 23.1 3.17 29.6 26.3 3.30 34.6 31.5 3.46 40.4 40.4 3.65 47.3 47.3 3.91 55.4 55.4 4.27
1575 16.7 15.4 2.89 21.1 19.4 3.02 25.5 23.3 3.15 29.8 26.5 3.27 34.9 31.7 3.42 40.8 40.8 3.60 47.8 47.8 3.85 56.0 56.0 4.20
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Heating
Indoor
Section Size
Heating
Capacity Power Capacity Power
CC5A/CD5AC 048 1.00 1.11 CK5A/CK5BT 048 1.00 0.98
CC5A/CD5AW 048 1.01 1.07 CK5A/CK5BW 048 1.00 0.98
CD5AA 048 1.01 1.07 CK5PA 048 1.00 0.98
CE3AA 048 1.02 1.04 CK5PT 048 1.00 0.98
CF5AA 048 1.00 0.98 CK5PW 048 1.00 0.98
CK3BA 048 1.02 1.03
COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE
CK5A/CK5BA 048 1.02 1.03 CC5A/CD5AW 048 1.00 1.02
CK5A/CK5BE 042 1.01 1.07 CD5AA 048 1.00 1.01
CK5A/CK5BT 048 1.02 1.03 CE3AA 048 1.00 1.00
CK5A/CK5BW 048 1.02 1.03 CK3BA 048 1.00 0.98
CK5PA 048 1.02 1.03 CK5A/CK5BA 048 1.00 0.98
CK5PE 042 1.01 1.07 CK5A/CK5BT 048 1.00 0.98
CK5PT 048 1.02 1.03 CK5A/CK5BW 048 1.00 0.98
CK5PW 048 1.02 1.03 CK5PA 048 1.00 0.98
F(A,B)4BN(F,B,C) 048 1.02 1.03 CK5PT 048 1.01 0.99
FC4CN(F,B) 048 1.02 1.02 CK5PW 048 1.00 0.98
FE4ANF 003 1.00 1.00
COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE
005 0.99 0.93 CC5A/CD5AW 048 1.00 1.01
FK4DNF 003 0.99 1.00 CD5AA 048 1.00 1.01
005 0.99 0.93 CE3AA 048 1.00 1.00
FV4BNF 003 1.00 1.00 CK3BA 048 1.00 0.98
005 0.99 0.93 CK5A/CK5BA 048 1.00 0.98
FX4BNF 042 1.02 1.01 CK5A/CK5BT 048 1.00 0.98
048 1.01 0.97 CK5A/CK5BW 048 1.00 0.98
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE CK5PA 048 1.00 0.98
CE3AA 048 1.01 1.02 CK5PT 048 1.00 0.98
CK3BA 048 1.01 1.01 CK5PW 048 1.00 0.98
CK5A/CK5BA 048 1.01 1.01
COILS + 355MAV042040 VARIABLE-SPEED FURNACE
CK5A/CK5BT 048 1.01 1.01 CC5A/CD5AC 048 0.99 1.09
CK5PA 048 1.01 1.01 CC5A/CD5AW 048 1.00 1.05
CK5PT 048 1.01 1.01 CD5AA 048 1.00 1.05
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE CK3BA 048 1.01 1.01
CC5A/CD5AW 048 1.00 1.02
COILS + 355MAV042060 VARIABLE-SPEED FURNACE
CD5AA 048 1.00 1.01 CC5A/CD5AC 048 0.99 1.08
CE3AA 048 1.00 1.00 CD5AA 048 1.00 1.04
CK3BA 048 1.00 0.98 CK5A/CK5BE 042 0.99 1.07
CK5A/CK5BA 048 1.00 0.98 CK5PE 042 0.99 1.07
See notes on page 32.
