—31—
HEAT PUMP HEATING PERFORMANCE Continued
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 27 37475767
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW† Total Int* kW†
650A048-D, E, F Outdoor Section With FV4(A,B)NF005 Indoor Section
65
1400 18.3 16.9 2.85 23.0 21.1 2.98 27.8 25.4 3.11 33.5 29.7 3.27 40.2 36.6 3.46 48.1 48.1 3.70 57.7 57.7 4.01 68.4 68.4 4.34
1600 18.6 17.1 2.86 23.2 21.3 2.98 28.1 25.6 3.10 33.8 30.0 3.24 40.6 37.0 3.42 48.7 48.7 3.64 58.5 58.5 3.94 68.9 68.9 4.23
1800 18.8 17.3 2.88 23.4 21.5 2.99 28.3 25.8 3.10 34.1 30.3 3.23 41.0 37.3 3.40 49.2 49.2 3.61 59.1 59.1 3.91 68.8 68.8 4.15
70
1400 17.9 16.5 3.01 22.6 20.8 3.14 27.5 25.1 3.29 33.1 29.4 3.45 39.6 36.1 3.65 47.4 47.4 3.89 56.8 56.8 4.21 67.5 67.5 4.58
1600 18.2 16.7 3.02 22.9 21.1 3.14 27.8 25.3 3.27 33.4 29.7 3.42 40.1 36.5 3.60 48.0 48.0 3.83 57.6 57.6 4.14 68.1 68.1 4.46
1800 18.4 16.9 3.03 23.1 21.3 3.15 28.0 25.6 3.27 33.7 29.9 3.41 40.5 36.8 3.58 48.5 48.5 3.80 58.2 58.2 4.10 68.3 68.30 4.37
75
1400 17.5 16.1 3.17 22.3 20.5 3.31 27.3 24.9 3.48 32.7 29.0 3.64 39.1 35.6 3.85 46.7 46.7 4.10 55.9 55.9 4.43 66.9 66.9 4.87
1600 17.8 16.4 3.18 22.5 20.7 3.31 27.5 25.1 3.45 33.0 29.3 3.61 39.6 36.0 3.79 47.3 47.3 4.03 56.7 56.7 4.35 67.3 67.3 4.70
1800 18.0 16.0 3.20 22.8 20.9 3.32 27.8 25.3 3.45 33.3 29.6 3.59 39.9 36.3 3.77 47.8 47.8 3.99 57.3 57.3 4.30 67.6 67.6 4.61
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Heating
Indoor
Section Size
Heating
Capacity Power Capacity Power
CC5A/CD5AA 060 1.01 1.12 CK5PT 060 1.00 1.00
CC5A/CD5AW 060 1.01 1.06 CK5PX 060 1.00 0.99
CD5PX 060 0.98 1.10
COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE
CE3AA 060 1.01 1.06 CC5A/CD5AW 060 0.99 1.08
CK3BA 060 1.01 1.03 CE3AA 060 0.99 1.02
CK5A/CK5BA 060 1.01 1.03 CK3BA 060 1.00 0.99
CK5A/CK5BT 060 1.01 1.03 CK5A/CK5BA 060 1.00 0.99
CK5A/CK5BX 060 1.02 1.04 CK5A/CK5BT 060 1.00 0.99
CK5PA 060 1.01 1.03 CK5A/CK5BX 060 1.00 0.99
CK5PT 060 1.01 1.03 CK5PA 060 1.00 0.99
CK5PX 060 1.02 1.04 CK5PT 060 1.00 0.99
F(A,B)4BN(F,B,C) 060 1.02 1.10 CK5PX 060 1.00 0.98
FB4BNB 070 1.01 1.02
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
FC4CN(F,B) 060 1.01 1.09 CC5A/CD5AA 060 0.98 1.09
FC4CNB 070 1.01 1.02 CC5A/CD5AW 048 0.99 1.02
FE4ANB 006 1.01 0.96 CK3BA 060 1.00 1.04
FE4ANF 005 1.00 1.00 CK5A/CK5BA 060 1.00 1.04
FK4DNB 006 1.01 0.96 CK5A/CK5BT 060 1.00 1.04
FK4DNF 005 1.01 1.01 CK5A/CK5BX 060 1.00 1.03
FV4BNB 006 1.01 0.96 CK5PA 060 1.00 1.04
FV4BNF 005 1.00 1.00 CK5PT 060 1.00 1.04
FX4BNB 060 1.01 1.02 CK5PX 060 1.00 1.03
FX4BNF 048 1.01 1.06
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE
CC5A/CD5AA 060 0.98 1.11
CE3AA 060 1.00 0.98 CC5A/CD5AW 048 0.99 1.10
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE
CD5PX 060 1.01 1.02
CD5PX 060 1.01 0.98 CK3BA 060 0.99 1.01
CE3AA 060 1.00 1.05 CK5A/CK5BA 060 0.99 1.01
CK3BA 060 1.00 0.99 CK5A/CK5BT 060 0.99 1.01
CK5A/CK5BA 060 0.99 1.02 CK5A/CK5BX 060 1.00 1.01
CK5A/CK5BT 060 1.00 0.99 CK5PA 060 0.99 1.01
CK5A/CK5BX 060 1.00 0.99 CK5PT 060 0.99 1.01
CK5PA 060 1.00 0.99 CK5PX 060 1.00 1.01
CK5PT 060 1.00 0.99
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CK5PX 060 1.00 0.99 CC5A/CD5AA 060 0.98 1.10
COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE
CC5A/CD5AW 048 0.99 1.10
CC5A/CD5AW 060 0.99 1.02 CK5A/CK5BA 060 0.99 1.01
CE3AA 060 0.99 1.02 CK5A/CK5BT 060 0.99 1.01
CK3BA 060 1.00 1.00 CK5A/CK5BX 060 1.00 1.01
CK5A/CK5BA 060 1.00 0.99 CK5PA 060 0.99 1.01
CK5A/CK5BT 060 1.00 1.00 CK5PT 060 0.99 1.01
CK5A/CK5BX 060 1.00 1.00 CK5PX 060 1.00 1.01
CK5PA 060 1.00 1.00 — — —
See notes on page 32.
