Fig. 24—HRVBBLVU Airflow During
Air Exchange
A92384
STALE AIR
FROM BUILDING
FRESH AIR
TO BUILDING
FRESH AIR
FROM OUTSIDE
STALE AIR
TO OUTSIDE
Fig. 22—HRVBBSVU Airflow During
Air Exchange
A92382
STALE AIR
FROM BUILDING
FRESH AIR
TO BUILDING
FRESH AIR
FROM OUTSIDE
STALE AIR
TO OUTSIDE
Fig. 25—HRVBBLVU Airflow During
Recirculation and Defrost
A92385
STALE AIR
FROM BUILDING
FILTERED AIR
TO BUILDING
Fig. 23—HRVBBSVU Airflow During
Recirculation and Defrost
A92383
STALE AIR
FROM BUILDING
FILTERED AIR
TO BUILDING
