PERFORMANCE DATA (cont.)
569J*25A CONDENSER ONLY RATINGS
SST (_F)
AIR TEMPERATURE ENTERING CONDENSER (_ F)
80 85 95 105 115 125
20
TC 159.2 154.5 144.5 133.9 122.5 110.2
kW 13.0 13.7 15.3 17.1 19.2 21.5
SDT 97.3 101.8 110.6 119.3 127.9 136.5
25
TC 176.1 171.0 160.2 148.8 136.5 123.2
kW 13.2 14.0 15.6 17.4 19.5 21.8
SDT 98.9 103.3 112.0 120.7 129.2 137.6
30
TC 194.2 188.6 176.9 164.5 151.3 136.9
kW 13.5 14.3 15.9 17.7 19.7 22.0
SDT 100.6 104.9 113.6 122.1 130.5 138.8
35
TC 213.5 207.4 194.7 181.2 166.8 151.2
kW 13.8 14.6 16.2 18.0 20.0 22.3
SDT 102.4 106.7 115.2 123.6 131.9 140.1
40
TC 234.1 227.4 213.5 198.8 183.1 166.1
kW 14.2 14.9 16.5 18.3 20.3 22.6
SDT 104.3 108.5 116.9 125.2 133.3 141.4
45
TC 255.9 248.6 233.3 217.3 200.1 181.7
kW 14.6 15.3 16.9 18.7 20.7 22.9
SDT 106.3 110.5 118.7 126.8 134.9 142.7
50
TC 279.0 270.9 254.2 236.7 218.1 197.8
kW 15.1 15.8 17.3 19.1 21.1 23.2
SDT 108.5 112.5 120.6 128.6 136.5 144.1
NOTE:
Condensing unit only ratings are at 45
_FSSTand95_F entering ---air temperature. EER = 12.9
569J*25D Dual Circuit CONDENSER ONLY RATINGS
SST (_F)
AIR TEMPERATURE ENTERING CONDENSER (_ F)
80 85 95 105 115 125
20
TC 160.3 155.5 145.3 134.3 122.5 109.6
kW 12.7 13.4 15.0 16.8 18.8 21.1
SDT 97.0 101.5 110.3 119.1 127.7 136.3
25
TC 177.2 171.9 160.8 149.0 136.3 122.3
kW 12.7 13.4 15.0 16.8 18.8 21.1
SDT 97.0 101.5 110.3 119.1 127.7 136.3
30
TC 195.1 189.4 177.4 164.5 150.7 135.6
kW 13.2 13.9 15.5 17.3 19.3 21.5
SDT 100.3 104.6 113.3 121.8 130.3 138.6
35
TC 214.3 208.0 194.9 180.9 165.9 149.5
kW 13.5 14.3 15.8 17.6 19.6 21.8
SDT 102.1 106.3 114.9 123.3 131.7 139.8
40
TC 234.6 227.7 213.4 198.2 181.7 163.9
kW 13.9 14.6 16.2 17.9 19.9 22.1
SDT 104.0 108.2 116.6 124.9 133.1 141.1
45
TC 256.3 258.7 242.3 224.9 206.2 186.1
kW 14.3 15.2 16.7 18.5 20.4 22.5
SDT 106.0 111.1 119.2 127.4 135.4 143.1
50
TC 279.1 272.0 254.7 236.3 216.6 195.4
kW 14.7 15.5 17.0 18.7 20.6 22.7
SDT 108.1 112.3 120.4 128.4 136.4 143.9
NOTE:
Condensing unit only ratings are at 45
_FSSTand95_F entering ---air temperature. EER = 13.0
LEGEND:
k W --- C o m p r e s s o r P o w e r
SDT --- Saturated Discharge Temperature at Compressor (
_F)
SST --- Saturated Suction Temperature (
_F)
TC --- Gross Cooling Capacity (1000 Btuh)
569J
