PERFORMANCE DATA (cont.)
569J*16A CONDENSER ONLY RATINGS
SST (_F)
AIR TEMPERATURE ENTERING CONDENSER (_ F)
80 85 95 105 115 125
20
TC 125.5 121.8 114.2 106.6 99.7 79.7
kW 10.5 11.2 12.6 14.2 16.0 17.5
SDT 98.6 103.4 113.0 122.7 134.9 136.0
25
TC 138.7 134.7 126.5 118.1 109.3 98.5
kW 10.7 11.4 12.8 14.3 16.0 17.9
SDT 100.0 104.7 114.2 123.6 132.9 140.5
30
TC 152.9 148.6 139.8 130.7 120.9 104.9
kW 10.9 11.6 13.0 14.6 16.2 17.8
SDT 101.4 106.2 115.5 125.0 133.6 139.4
35
TC 168.2 163.5 154.1 144.2 133.6 121.2
kW 11.2 11.8 13.2 14.8 16.5 18.1
SDT 102.9 107.5 117.0 126.2 134.8 142.1
40
TC 184.9 179.4 169.3 158.7 147.6 135.1
kW 11.5 12.0 13.5 15.1 16.8 18.5
SDT 105.2 108.9 118.5 127.7 136.7 144.5
45
TC 202.1 196.7 185.7 174.3 162.5 150.4
kW 11.7 12.4 13.9 15.6 17.5 19.6
SDT 106.4 111.2 120.9 130.7 140.4 150.2
50
TC 220.6 214.7 202.1 190.0 174.6 159.6
kW 11.9 12.6 13.9 15.4 16.9 18.5
SDT 107.2 111.7 120.4 129.4 136.9 144.9
NOTE:
Condensing unit only ratings are at 45
_FSSTand95_F entering ---air temperature. EER = 12.7
569J*16D Dual Circuit CONDENSER ONLY RATINGS
SST (_F)
AIR TEMPERATURE ENTERING CONDENSER (_ F)
80 85 95 105 115 125
20
TC 127.6 123.7 116.0 108.1 99.7 90.2
kW 10.0 10.6 11.9 13.4 14.9 16.6
SDT 96.0 100.5 109.8 119.2 128.3 137.0
25
TC 140.9 136.7 128.3 119.5 110.4 101.2
kW 10.0 10.6 11.9 13.4 14.9 16.6
SDT 96.0 100.5 109.8 119.2 128.3 137.0
30
TC 155.0 150.5 141.3 132.0 122.3 111.4
kW 10.4 11.0 12.3 13.7 15.3 17.0
SDT 98.7 103.3 112.4 121.5 130.6 139.1
35
TC 170.1 165.3 155.4 145.2 134.4 123.3
kW 10.6 11.2 12.5 14.0 15.5 17.2
SDT 100.1 104.7 113.8 122.8 131.7 140.4
40
TC 186.3 181.0 170.3 159.0 147.3 134.9
kW 10.8 11.4 12.8 14.2 15.8 17.4
SDT 101.6 106.1 115.1 124.0 132.8 141.4
45
TC 203.4 197.6 185.7 173.5 160.6 147.2
kW 11.1 11.7 13.0 14.4 16.0 17.6
SDT 103.2 107.6 116.5 125.4 134.0 142.5
50
TC 221.4 214.9 202.0 188.6 174.5 159.7
kW 11.4 12.0 13.3 14.7 16.2 17.9
SDT 104.8 109.2 118.0 126.7 135.2 143.5
NOTE:
Condensing unit only ratings are at 45
_FSSTand95_F entering ---air temperature. EER = 13.0
LEGEND:
k W --- C o m p r e s s o r P o w e r
SDT --- Saturated Discharge Temperature at Compressor (
_F)
SST --- Saturated Suction Temperature (
_F)
TC --- Gross Cooling Capacity (1000 Btuh)
