Bryant LEGACY 569J User Manual

20
PERFORMANCE DATA (cont.)
569J*14A CONDENSER ONLY RATINGS
SST (_F)
AIR TEMPERATURE ENTERING CONDENSER (_ F)
80 85 95 100 105 115
20
TC 100.8 97.4 90.3 86.6 83.0 75.5
kW 8.48 8.97 10.00 10.53 11.07 12.19
SDT 98.0 102.6 111.8 116.4 120.9 130.0
25
TC 111.8 108.1 100.5 96.6 92.7 84.7
kW 8.66 9.15 10.20 10.75 11.31 12.47
SDT 99.6 104.1 113.2 117.7 122.3 131.3
30
TC 122.9 118.9 110.7 106.6 102.4 93.9
kW 8.84 9.35 10.41 10.97 11.55 12.75
SDT 101.3 105.8 114.8 119.3 123.8 132.7
35
TC 134.9 130.6 121.9 117.4 113.0 103.8
kW 9.05 9.55 10.64 11.21 11.80 13.03
SDT 103.1 107.6 116.5 120.9 125.4 134.2
40
TC 147.7 143.0 133.7 128.9 124.1 114.3
kW 9.27 9.78 10.88 11.47 12.07 13.32
SDT 105.1 109.5 118.3 122.8 127.1 135.8
45
TC 161.1 156.2 146.1 141.0 135.8 125.4
kW 9.51 10.03 11.15 11.73 12.34 13.61
SDT 107.2 111.6 120.3 124.7 129.0 137.5
50
TC 175.4 170.1 159.3 153.8 148.3 137.1
kW 9.78 10.30 11.42 12.02 12.63 13.92
SDT 109.5 113.8 122.4 126.7 130.9 139.4
NOTE:
Condensing unit only ratings are at 45
_FSSTand95_F entering ---air temperature. EER = 12.0
569J*14D Dual Circuit CONDENSER ONLY RATINGS
SST (_F)
AIR TEMP ENT CONDENSER (_F)
85 95 100 105 115 120
20
TC 93.24 86.18 82.60 78.94 71.54 67.78
kW 9.22 10.36 10.96 11.56 12.76 13.37
SDT 104.4 113.3 117.8 122.2 130.9 135.2
25
TC 103.39 95.91 92.05 88.15 80.16 76.08
kW 9.42 10.60 11.21 11.83 13.10 13.73
SDT 106.1 114.9 119.3 123.7 132.3 136.6
30
TC 114.29 106.19 102.04 97.79 89.15 84.74
kW 9.63 10.84 11.46 12.10 13.41 14.07
SDT 107.8 116.6 120.9 125.3 133.8 138.0
35
TC 125.69 116.93 112.44 107.84 105.72 93.69
kW 9.84 11.07 11.71 12.36 13.70 14.38
SDT 109.5 118.2 122.6 126.8 135.2 139.4
40
TC 137.57 128.07 123.21 118.21 108.08 102.90
kW 10.05 11.30 11.95 12.61 13.98 14.68
SDT 111.3 119.9 124.2 128.4 136.7 140.8
45
TC 149.86 139.53 134.26 128.83 117.83 112.22
kW 10.27 11.53 12.18 12.85 14.24 14.95
SDT 113.1 121.6 125.8 130.0 138.1 142.1
50
TC 162.51 151.29 145.56 139.64 127.71 121.55
kW 10.50 11.76 12.42 13.09 14.48 15.20
SDT 114.9 123.3 127.5 131.6 139.6 143.5
NOTE:
Condensing unit only ratings are at 45
_FSSTand95_F entering ---air temperature. EER = 13.0
LEGEND:
k W --- C o m p r e s s o r P o w e r
SDT --- Saturated Discharge Temperature at Compressor (
_F)
SST --- Saturated Suction Temperature (
_F)
TC --- Gross Cooling Capacity (1000 Btuh)
