29
PERFORMANCE DATA (cont.)
569J*12D -- 524J*12 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (db) EA (db) EA (db) EA (db) EA (db)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
3000 Cfm
EA (wb)
58
THC 111.6 111.6 125.3 107.3 107.3 120.5 102.6 102.6 115.2 97.3 97.3 109.4 91.7 91.7 103.0
SHC 97.9 111.6 125.3 94.1 107.3 120.5 89.9 102.6 115.2 85.3 97.3 109.4 80.3 91.7 103.0
62
THC 115.9 115.9 119.8 110.5 110.5 117.1 104.8 104.8 114.2 98.3 98.3 110.7 92.4 92.4 106.2
SHC 88.6 104.2 119.8 86.0 101.5 117.1 83.2 98.7 114.2 79.9 95.3 110.7 76.2 91.2 106.2
67
THC 125.6 125.6 125.6 119.9 119.9 119.9 113.7 113.7 113.7 107.1 107.1 107.1 99.6 99.6 99.6
SHC 71.9 87.6 103.3 69.4 85.1 100.8 66.8 82.5 98.1 63.9 79.6 95.3 60.8 76.5 92.2
72
THC 135.6 135.6 135.6 129.6 129.6 129.6 123.1 123.1 123.1 116.1 116.1 116.1 108.4 108.4 108.4
SHC 55.0 70.8 86.6 52.6 68.4 84.2 50.1 65.9 81.7 47.4 63.2 79.0 44.5 60.3 76.1
76
THC --- 143.6 143.6 --- 137.4 137.4 --- 130.7 130.7 --- 123.3 123.3 --- 115.2 115.2
SHC --- 57.3 73.6 --- 55.1 71.4 --- 52.7 68.9 --- 50.1 66.2 --- 47.4 63.4
3500 Cfm
EA (wb)
58
THC 117.1 117.1 131.6 112.5 112.5 126.4 107.5 107.5 120.8 102.0 102.0 114.7 95.7 95.7 107.7
SHC 102.6 117.1 131.6 98.6 112.5 126.4 94.2 107.5 120.8 89.4 102.0 114.7 83.8 95.7 107.7
62
THC 119.3 119.3 130.8 113.8 113.8 127.8 108.1 108.1 123.7 102.1 102.1 119.1 95.7 95.7 111.7
SHC 95.1 112.9 130.8 92.3 110.0 127.8 88.9 106.3 123.7 85.1 102.1 119.1 79.7 95.7 111.7
67
THC 128.8 128.8 128.8 122.8 122.8 122.8 116.4 116.4 116.4 109.5 109.5 109.5 101.9 101.9 101.9
SHC 76.0 94.1 112.2 73.5 91.6 109.7 70.8 88.9 107.0 68.0 86.1 104.2 64.9 82.9 101.0
72
THC 138.6 138.6 138.6 132.5 132.5 132.5 125.8 125.8 125.8 118.4 118.4 118.4 110.5 110.5 110.5
SHC 56.5 74.8 93.0 54.2 72.4 90.6 51.7 69.9 88.1 48.9 67.1 85.3 46.0 64.2 82.4
76
THC --- 146.6 146.6 --- 140.2 140.2 --- 133.2 133.2 --- 125.6 125.6 --- --- ---
SHC --- 59.4 78.0 --- 57.1 75.7 --- 54.7 73.3 --- 52.2 70.6 --- --- ---
4000 Cfm
EA (wb)
58
THC 121.6 121.6 136.6 116.7 116.7 131.2 111.4 111.4 125.3 105.7 105.7 118.9 99.2 99.2 111.7
SHC 106.5 121.6 136.6 102.2 116.7 131.2 97.6 111.4 125.3 92.5 105.7 118.9 86.8 99.2 111.7
62
THC 122.2 122.2 140.3 117.0 117.0 135.6 111.4 111.4 130.0 105.7 105.7 123.4 99.2 99.2 115.9
SHC 100.7 120.5 140.3 97.0 116.3 135.6 92.8 111.4 130.0 88.0 105.7 123.4 82.6 99.2 115.9
67
THC 131.1 131.1 131.1 125.0 125.0 125.0 118.5 118.5 118.5 111.4 111.4 112.6 103.7 103.7 109.4
SHC 79.9 100.4 120.8 77.4 97.8 118.3 74.7 95.1 115.6 71.8 92.2 112.6 68.7 89.0 109.4
72
THC 140.9 140.9 140.9 134.6 134.6 134.6 127.7 127.7 127.7 120.3 120.3 120.3 112.1 112.1 112.1
SHC 57.9 78.6 99.2 55.6 76.2 96.8 53.1 73.7 94.2 50.4 70.9 91.5 47.5 68.0 88.5
76
THC --- 148.8 148.8 --- 142.3 142.3 --- 135.2 135.2 --- --- --- --- --- ---
SHC --- 61.3 82.2 --- 59.1 80.0 --- 56.7 77.5 --- --- --- --- --- ---
4500 Cfm
EA (wb)
58
THC 125.3 125.3 140.9 120.2 120.2 135.3 114.8 114.8 129.1 108.8 108.8 122.4 102.4 102.4 115.2
SHC 109.7 125.3 140.9 105.2 120.2 135.3 100.4 114.8 129.1 95.2 108.8 122.4 89.5 102.4 115.2
62
THC 125.3 125.3 146.2 120.2 120.2 140.3 114.7 114.7 134.0 108.8 108.8 127.1 102.4 102.4 119.6
SHC 104.4 125.3 146.2 100.1 120.2 140.3 95.5 114.7 134.0 90.5 108.8 127.1 85.1 102.4 119.6
67
THC 133.0 133.0 133.0 126.8 126.8 126.8 120.1 120.1 123.8 112.9 112.9 120.7 105.1 105.1 117.3
SHC 83.6 106.4 129.2 81.1 103.8 126.6 78.3 101.0 123.8 75.4 98.0 120.7 72.2 94.8 117.3
72
THC 142.8 142.8 142.8 136.3 136.3 136.3 129.3 129.3 129.3 121.7 121.7 121.7 113.3 113.3 113.3
SHC 59.3 82.2 105.1 57.0 79.9 102.8 54.4 77.3 100.2 51.7 74.6 97.5 48.8 71.6 94.5
76
THC --- 150.5 150.5 --- 143.9 143.9 --- --- --- --- --- --- --- --- ---
SHC --- 63.1 86.4 --- 60.9 84.1 --- --- --- --- --- --- --- --- ---
5000 Cfm
EA (wb)
58
THC 128.4 128.4 144.5 123.2 123.2 138.7 117.6 117.6 132.3 111.4 111.4 125.4 104.7 104.7 117.9
SHC 112.4 128.4 144.5 107.8 123.2 138.7 102.8 117.6 132.3 97.4 111.4 125.4 91.5 104.7 117.9
62
THC 128.4 128.4 149.9 123.2 123.2 143.9 117.5 117.5 137.3 111.4 111.4 130.2 104.7 104.7 122.4
SHC 106.9 128.4 149.9 102.5 123.2 143.9 97.8 117.5 137.3 92.6 111.4 130.2 87.0 104.7 122.4
67
THC 134.6 134.6 137.2 128.3 128.3 134.5 121.5 121.5 131.6 114.2 114.2 128.3 106.3 106.3 124.6
SHC 87.1 112.2 137.2 84.6 109.5 134.5 81.8 106.7 131.6 78.8 103.6 128.3 75.5 100.1 124.6
72
THC 144.2 144.2 144.2 137.7 137.7 137.7 130.6 130.6 130.6 122.8 122.8 122.8 114.4 114.4 114.4
SHC 60.6 85.8 111.0 58.3 83.5 108.6 55.8 80.9 106.1 53.0 78.2 103.3 50.1 75.2 100.3
76
THC --- 151.9 151.9 --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- 64.9 90.4 --- --- --- --- --- --- --- --- --- --- --- ---
--- Not operational
THC --- Total Cooling Capacity, Gross (1,000 Btuh)
SHC --- Sensible Cooling Capacity, Gross (1,000 Btuh)
