39
PERFORMANCE DATA (cont.)
569J*25A -- 524J*25 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (db) EA (db) EA (db) EA (db) EA (db)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
6000 Cfm
EA (wb)
58
THC 221.5 221.5 248.3 213.5 213.5 239.8 204.9 204.9 230.0 195.3 195.3 219.4 184.5 184.5 207.4
SHC 194.2 221.2 248.3 187.3 213.5 239.8 179.7 204.9 230.0 171.2 195.3 219.4 161.7 184.5 207.4
62
THC 232.4 232.4 232.9 222.4 222.4 228.1 211.4 211.4 222.6 199.4 199.4 216.7 186.5 186.5 209.6
SHC 173.9 203.4 232.9 169.1 198.6 228.1 163.7 193.2 222.6 157.9 187.3 216.7 151.3 180.5 209.6
67
THC 251.7 251.7 251.7 240.8 240.8 240.8 228.9 228.9 228.9 215.9 215.9 215.9 201.6 201.6 201.6
SHC 141.6 170.7 199.8 136.8 166.0 195.3 131.7 161.1 190.4 126.2 155.6 185.0 120.3 149.7 179.2
72
THC 272.8 272.8 272.8 260.8 260.8 260.8 247.6 247.6 247.6 233.4 233.4 233.4 217.8 217.8 217.8
SHC 110.4 138.3 166.1 105.5 133.8 162.0 100.3 128.9 157.5 94.8 123.6 152.4 88.9 117.9 147.0
76
THC --- 290.9 290.9 --- 278.1 278.1 --- 263.7 263.7 --- 248.5 248.5 --- 231.6 231.6
SHC --- 111.5 144.5 --- 106.8 139.8 --- 103.0 136.0 --- 98.3 123.1 --- 92.9 120.2
7000 Cfm
EA (wb)
58
THC 232.1 232.1 260.6 223.5 223.5 251.1 214.2 214.2 240.7 203.9 203.9 229.2 192.4 192.4 216.4
SHC 203.5 232.1 260.6 195.9 223.5 251.1 187.7 214.2 240.7 178.6 203.9 229.2 168.5 192.4 216.4
62
THC 238.9 238.9 253.7 228.3 228.3 248.2 217.1 217.1 242.1 205.0 205.0 234.5 192.8 192.8 222.1
SHC 186.0 219.8 253.7 180.8 214.5 248.2 175.1 208.6 242.1 168.4 201.5 234.5 159.1 190.6 222.1
67
THC 258.3 258.3 258.3 246.8 246.8 246.8 234.4 234.4 234.4 220.8 220.8 220.8 205.9 205.9 205.9
SHC 149.2 182.8 216.5 144.4 178.1 211.8 139.2 173.0 206.7 133.6 167.4 201.2 127.5 161.4 195.3
72
THC 279.3 279.3 279.3 266.7 266.7 266.7 253.0 253.0 253.0 238.3 238.3 238.3 222.0 222.0 222.0
SHC 113.2 145.9 178.5 108.3 141.2 174.1 103.1 136.3 169.4 97.6 130.9 164.2 91.5 125.1 158.6
76
THC --- 297.5 297.5 --- 283.8 283.8 --- 269.2 269.2 --- 253.2 253.2 --- 235.5 235.5
SHC --- 116.1 154.6 --- 112.0 138.2 --- 107.4 137.4 --- 102.4 133.9 --- 96.7 129.1
8000 Cfm
EA (wb)
58
THC 240.8 240.8 270.6 231.8 231.8 260.5 221.8 221.8 249.4 210.9 210.9 237.2 198.8 198.8 223.6
SHC 211.0 240.8 270.6 203.0 231.8 260.5 194.2 221.8 249.4 184.6 210.9 237.2 173.9 198.8 223.6
62
THC 244.2 244.2 271.9 233.5 233.5 265.4 222.6 222.6 255.7 211.0 211.0 245.3 198.8 198.8 232.0
SHC 196.6 234.3 271.9 190.9 228.2 265.4 183.3 219.5 255.7 175.2 210.2 245.3 165.5 198.8 232.0
67
THC 263.5 263.5 263.5 251.6 251.6 251.6 238.7 238.7 238.7 224.6 224.6 224.6 209.2 209.2 210.8
SHC 156.4 194.4 232.4 151.5 189.6 227.6 146.3 184.4 222.4 140.6 178.7 216.9 134.5 172.6 210.8
72
THC 284.4 284.4 284.4 271.3 271.3 271.3 257.3 257.3 257.3 242.0 242.0 242.0 225.4 225.4 225.4
SHC 115.9 153.0 190.2 110.9 148.3 185.7 105.8 143.3 180.9 100.2 137.9 175.6 94.2 132.0 169.9
76
THC --- 302.5 302.5 --- 288.4 288.4 --- 273.4 273.4 --- 256.8 256.8 --- --- ---
SHC --- 120.4 153.1 --- 116.0 150.4 --- 111.3 146.9 --- 106.0 142.5 --- --- ---
9000 Cfm
EA (wb)
58
THC 248.2 248.2 279.1 238.7 238.7 268.5 228.3 228.3 256.8 216.8 216.8 244.0 204.1 204.1 229.7
SHC 217.4 248.2 279.1 209.0 238.7 268.5 199.8 228.3 256.8 189.7 216.8 244.0 178.5 204.1 229.7
62
THC 249.3 249.3 285.8 238.9 238.9 277.7 228.3 228.3 266.5 216.8 216.8 253.2 204.1 204.1 238.4
SHC 204.9 245.4 285.8 198.4 238.0 277.7 190.1 228.3 266.5 180.4 216.8 253.2 169.8 204.1 238.4
67
THC 267.7 267.7 267.7 255.5 255.5 255.5 242.2 242.2 242.2 227.7 227.7 232.0 212.0 212.0 225.6
SHC 163.4 205.6 247.7 158.4 200.6 242.9 153.1 195.3 237.6 147.3 189.7 232.0 141.1 183.4 225.6
72
THC 288.5 288.5 288.5 275.2 275.2 275.2 260.8 260.8 260.8 245.1 245.1 245.1 228.1 228.1 228.1
SHC 118.4 159.9 201.4 113.5 155.2 196.8 108.3 150.1 191.9 102.7 144.6 186.5 96.6 138.7 180.7
76
THC --- 306.6 306.6 --- 292.3 292.3 --- 276.7 276.7 --- --- --- --- --- ---
SHC --- 124.2 162.9 --- 119.7 159.4 --- 114.8 155.2 --- --- --- --- --- ---
10,000 Cfm
EA (wb)
58
THC 254.7 254.7 286.5 244.7 244.7 275.3 233.9 233.9 263.2 221.9 221.9 249.8 208.7 208.7 234.9
SHC 222.9 254.7 286.5 214.1 244.7 275.3 204.6 233.9 263.2 194.0 221.9 249.8 182.5 208.7 234.9
62
THC 254.6 254.6 297.3 244.8 244.8 285.3 233.9 233.9 273.1 221.9 221.9 259.2 208.6 208.6 243.8
SHC 212.0 254.6 297.3 203.4 244.4 285.3 194.6 233.9 273.1 184.5 221.9 259.2 173.4 208.6 243.8
67
THC 271.3 271.3 271.3 258.7 258.7 258.7 245.1 245.1 252.3 230.3 230.3 246.7 214.0 214.0 239.7
SHC 170.0 216.4 262.7 165.0 211.4 257.7 159.6 206.0 252.3 153.9 200.3 246.7 147.3 193.5 239.7
72
THC 292.0 292.0 292.0 278.4 278.4 278.4 263.7 263.7 263.7 247.4 247.4 247.4 230.0 230.0 230.0
SHC 120.9 166.6 212.3 116.0 161.8 207.6 110.7 156.7 202.6 105.0 151.0 197.1 98.9 145.1 191.2
76
THC --- 310.1 310.1 --- 295.3 295.3 --- --- --- --- --- --- --- --- ---
SHC --- 127.8 171.4 --- 123.2 167.5 --- --- --- --- --- --- --- --- ---
--- Not operational
THC --- Total Cooling Capacity, Gross (1,000 Btuh)
SHC --- Sensible Cooling Capacity, Gross (1,000 Btuh)
