Bryant LEGACY 569J - 569 J*12 A Cooling; 569 J*12 D Cooling

44
ELECTRICAL DATA (cont.)
569J*12A COOLING WITHOUT POWERED CONVENIENCE OUTLET
V --- P h --- H z
VOLTAGE RANGE COMP 1 OFM (ea) POWER SUPPLY
MIN MAX RLA LRA WATTS FLA MCA Fuse
208/230--- 3---60 187 253 30.1 225 325 1.5 40.6 60
4 6 0 --- 3 --- 6 0 414 506 16.7 114 325 0.8 22.5 30
5 7 5 --- 3 --- 6 0 518 633 12.2 80 325 0.7 16.7 25
569J*12A COOLING WITH POWERED CONVENIENCE OUTLET
V --- P h --- H z
VOLTAGE RANGE COMP 1 OFM (ea) POWER SUPPLY
MIN MAX RLA LRA WATTS FLA MCA Fuse
208/230--- 3---60 187 253 30.1 225 325 1.5 45.4 60
4 6 0 --- 3 --- 6 0 414 506 16.7 114 325 0.8 24.7 30
5 7 5 --- 3 --- 6 0 518 633 12.2 80 325 0.7 18.4 30
569J*12D COOLING WITHOUT POWERED CONVENIENCE OUTLET
V --- P h --- H z
VOLTAGE RANGE COMP 1 COMP 2 OFM (ea) POWER SUPPLY
MIN MAX RLA LRA RLA LRA WATTS FLA MC A Fuse
208/230--- 3---60 187 253 15.9 110 15.9 110 325 1.5 38.8 50
4 6 0 --- 3 --- 6 0 414 506 7.7 52 7.7 52 325 0.8 18.9 25
5 7 5 --- 3 --- 6 0 518 633 5.7 39 5.7 39 325 0.7 14.2 20
569J*12D COOLING WITH POWERED CONVENIENCE OUTLET
V --- P h --- H z
VOLTAGE RANGE COMP 1 COMP 2 OFM (ea) POWER SUPPLY
MIN MAX RLA LRA RLA LRA WATTS FLA MC A Fuse
208/230--- 3---60 187 253 15.9 110 15.9 110 325 1.5 43.6 50
4 6 0 --- 3 --- 6 0 414 506 7.7 52 7.7 52 325 0.8 21.1 25
5 7 5 --- 3 --- 6 0 518 633 5.7 39 5.7 39 325 0.7 15.9 20
569J
