Bryant LEGACY 569J User Manual

45
ELECTRICAL DATA (cont.)
569J*14A COOLING WITHOUT POWERED CONVENIENCE OUTLET
V --- P h --- H z
VOLTAGE RANGE COMP 1 OFM (ea) POWER SUPPLY
MIN MAX RLA LRA WATTS FLA MCA Fuse
208/230--- 3---60 187 253 48.1 245 325 1.5 63.1 80
4 6 0 --- 3 --- 6 0 414 506 18.6 125 325 0.8 24.9 30
5 7 5 --- 3 --- 6 0 518 633 14.7 100 325 0.7 19.8 30
569J*14A COOLING WITH POWERED CONVENIENCE OUTLET
V --- P h --- H z
VOLTAGE RANGE COMP 1 OFM (ea) POWER SUPPLY
MIN MAX RLA LRA WATTS FLA MCA Fuse
208/230--- 3---60 187 253 48.1 245 325 1.5 67.9 80
4 6 0 --- 3 --- 6 0 414 506 18.6 125 325 0.8 27.1 45
5 7 5 --- 3 --- 6 0 518 633 14.7 100 325 0.7 21.5 30
569J*14D COOLING WITHOUT POWERED CONVENIENCE OUTLET
V --- P h --- H z
VOLTAGE RANGE COMP 1 COMP 2 OFM (ea) POWER SUPPLY
MIN MAX RLA LRA RLA LRA WATTS FLA MC A Fuse
208/230--- 3---60 187 253 22.40 149 22.40 149 325 1.5 53.4 60
4 6 0 --- 3 --- 6 0 414 506 10.6 75 10.6 75 325 0.8 25.5 30
5 7 5 --- 3 --- 6 0 518 633 7.7 54 7.7 54 325 0.7 18.7 25
569J*14D COOLING WITH POWERED CONVENIENCE OUTLET
V --- P h --- H z
VOLTAGE RANGE COMP 1 COMP 2 OFM (ea) POWER SUPPLY
MIN MAX RLA LRA RLA LRA WATTS FLA MC A Fuse
208/230--- 3---60 187 253 22.40 149 22.40 149 325 1.5 58.2 80
4 6 0 --- 3 --- 6 0 414 506 10.6 75 10.6 75 325 0.8 27.7 35
5 7 5 --- 3 --- 6 0 518 633 7.7 54 7.7 54 325 0.7 20.4 25
