Bryston 9BSST - Performance Analysis Part 2; Typical THD+N Sweep Graph; Typical IMD Sweep Graph; Damping Factor Graph

Typical THD+N Sweep
4 ohm 200w
8 ohm 120w
Typical IMD Sweep
8 ohm 120w
4 ohm 200w
9BSST FIVE CHANNEL POWER AMPLIFIER
10
Graph shows that distortion is
essentially unaffected by load.
4v balanced input shown.
Damping Factor
8 ohm reference
Typical Crosstalk
channel 2 reading with
channels 1 & 3 driven to
120w into 8 ohms
channel 2 reading with
channels 1 & 3 driven to
400w into 4 ohms
