52
Wall mounting template
• Using the drawing as your template, mark, then drill
two holes for the two screws and wall plugs (if needed).
• Insert the screws, leaving about 5mm sticking out
from the wall.
• Hook the slots on the back of the charger over the
screw heads protruding from the wall.
50mm
