8000302 | Instructions for use RUCK Podiatry Couch MOON | REV 04 |
Revision status 08/09/2023
44
Operation and use
5.7.2 Changing sides of the hand wheel
The hand wheel can be converted to position it on the other side of the podiatry
couch. The hand wheel must not stick out to the front or back.
CAUTION
Only position the hand wheel on the
sides (area A or B).
If positioned in the area marked X, it
poses a risk of injury to the operator.
Also, if wrongly positioned, the podiatry
couch could become damaged.
A
B
X X
1. Tilt the seat backwards to gain access for
fastening the hand wheel.
2. Use a screwdriver to unscrew the two
marked slotted screws.
3. Position the hand wheel on the side in area
A or B.
4. Tighten the two slotted screws again.
