Page 9
INSTALLATION OF MODEL 36 (WS)
WITH OPTIONAL WOODEN SURROUND (KIT#PAKDM36)
1. When choosing right location for your heater and surround (mantel) keep following in
mind:
NOTE: Due to high temperatures, this heater should be located out of traffic areas and
away from furniture and draperies.
NOTE: Kit No. (PAKDM36) Optional Wooden Surround (Mantel) for Model 36 (WS).
CAUTION: THE INSTALLATION MUST CONFORM WITH LOCAL CODES OR,
IN THE ABSENCE OF LOCAL CODES, WITH NATIONAL FUEL GAS CODES,
ANSI Z223.1/NFPA 54.
NOTE: See page 15 for “Gas Connection” and page 16 for “Gas Pressure Check”.
WARNING: YOUNG CHILDREN SHOULD BE CAREFULLY SUPERVISED WHEN
THEY ARE IN SAME ROOM WITH APPLIANCE.
DO NOT PLACE CLOTHING OR OTHER FLAMMABLE MATERIAL ON OR NEAR
THE APPLIANCE
2. Screen(s) can not be removed or altered (Position screen (s) in closed position before
leaving heater unattended).
3. Follow instructions for assembly of (Optional) Wooden Surround (Mantel). See
instructions supplied with surround.
4. After mantel has been assembled, slide heater from rear into opening of surround.
NOTE: Place a cloth or blanket over front portions of surround as not to mar wood.
5. Center heater in opening of surround.
6. Fasten surround (mantel) to hearth by using 1/2" wood screws.
7. Insert nine (9) wood screws provided with surround through slots on nailing flange and
secure in place.
8. Position surround (mantel) and fireplace into desired location.
NOTE: Hook gas supply line into heater. Check for leaks using soap and water, not an
open flame.
NOTE: At this point, you may want to anchor surround (mantel) to wall or floor.
