Page 26
THERMOSTAT CONTROL OPERATION
1. The thermostat control on this heater differs from standard thermostats. Standard
thermostats simply turn burner on and off. The thermostat used on this heater senses
room temperature and adjusts amount of gas flow to burner. This will increase or
decrease flame height. At times, room may exceed set temperature, which will cause
the burner to shut off. When room temperature drops below the thermostat setting,
burner will cycle itself on again. The control knob can be set to any level between
“LO” and “HI”.
NOTE: The thermostat sensing bulb measures temperature of air near heater
cabinet.This may not always agree with room temperature (depending on
housing construction, installation location, room size, open air temperatures,
etc.). Frequent use of your heater will allow you to determine your personal
comfort levels.
MANUAL LIGHTING PROCEDURE
1. If pilot cannot be lit with piezo, it can be manually lit with use of a paper match and a
lighter rod.
2. Open access panel door located at bottom front of appliance.
3. Place the match in holder and light. With the left hand, turn control knob
counterclockwise to “PILOT”position. Press in gas control knob for fifteen
(15) seconds.
4. Use rod to light match and ignite pilot. The pilot is located in front of rear log and
burner on right hand side of appliance.
5. Continue to hold control knob for an additional one (1) minute to ensure pilot is
lit.
6. Turn control knob counterclockwise to “ON” position. Push
“ON/ OFF” toggle switch to “ON” position. The main burner should light.
7. Close access panel door.
8. Turn on all electrical power to appliance.
NOTE: This unit may be used with an optional Wall Thermostat. If so, Wall Thermostat needs
to be set at a higher temperature than room temperature.
