Page 30
MANUAL LIGHTING PROCEDURE
1. If pilot cannot be lit with piezo, it can be manually lit with use of a paper match and a
lighter rod.
2. Open access panel door located at bottom front of appliance.
3. Place the match in holder and light. With left hand, turn control knob
counterclockwise to “PILOT”position. Press in gas control knob for fifteen
(15) seconds.
4. Use rod to light match and ignite pilot. The pilot is located in front of rear log and
burner on right hand side of appliance.
5. Continue to hold control knob for an additional one (1) minute to ensure pilot is
lit.
6. Turn control knob counterclockwise to “ON” position. Push
“ON/ OFF” toggle switch to “ON” position. The main burner should light.
7. Close access panel door.
8. Turn on all electrical power to appliance.
NOTE: This unit may be used with an optional Wall Thermostat. If so, Wall Thermostat
needs to be set at a higher temperature than room temperature.
