Page 33
WARNING:
ELECTRICAL GROUNDING INSTRUCTION:
THIS APPLIANCE IS EQUIPPED WITH A THREE-PRONG (GROUNDING) PLUG
FOR YOUR PROTECTION AGAINST SHOCK HAZARD AND SHOULD BE
PLUGGED DIRECTLY INTO A PROPERLY GROUNDED THREE-PRONG
RECEPTACLE.
NOTE: #PESBR084 Blower Motor
Rating: 120 volts/60HZ/1.1 Amps.
See Figure 16, page 32 for wiring diagram.
NOTE: For convenience, allow licensed electrician to install properly grounded
3-plug receptacle near unit.
ROOM BLOWER INSTALLATION AND OPERATION INSTRUCTIONS
The room air blower is located at rear of unit in bottom chamber. To remove or replace
blower, open lower louvered access door. The motor is located right center in rear. Remove
two (2) hex head screws holding motor and motor bracket to outer bottom of unit. Unhook
two motor wires and remove the motor from unit. Next remove (2) screws that fasten the
motor bracket to motor. Locate motor bracket on new motor in same position as with the old.
Using two (2) hex head screws fasten the bracket to new motor. Place new motor into lower
compartment.
NOTE: Make sure motor opening 1"x 5" is behind inner wall of the stove and not touching
any metal. Fasten new motor and bracket to motor support on bottom of unit. Hook motor
wires as shown in diagram on page 32.
Installation and repairs should be performed by a qualified service person. The appliance should
be inspected before use and at least annually by a professional service person. More frequent
cleaning may be required due to excessive lint from carpeting, bedding material, etc. It is
imperative that control compartments, burners and circulating air passageways of appliance be
kept clean.
