Page 46
REPLACEMENT PARTS FOR
SIT MILLIVOLT VALVE ESB. BASE
(PICTURE ON PAGE 47)
A parts list with exploded view follows. Always include correct name, part number and model
number of heater when ordering service parts.
KEY# PART DESCRIPTION PART NUMBER
1. O.D.S. PILOT (L.P.) O.P. ASSEMBLY PE 8404C
1. O.D.S. PILOT (NAT) O.P. ASSEMBLY PE 8204C
2. GENERATOR ASSEMBLY (Part of Pilot Assembly)
3. PILOT TUBE 3/16" MF 31612 ALMTUB
4. GENERATOR WIRE (Part of Pilot Assembly)
5. REAR BURNER PO VE1002
FRONT BURNER PO 383436
6. INLET ELBOW PH 4966
7. 3/8" COMP. NUT & SLEEVE PH 616 & PH 606
8. 3/8" BURNER SUPPLY TUBE (FLEX)
- 3 pieces 12" PO T6-12
9. 24" SWITCH WIRES PE 30JUMPER
10. CARLING SWITCH
(AUTO/OFF/MANUAL) PE RC211RB
11. PIEZO STRIKER PE 124461
12. PIEZO 18" IGNITOR WIRE PE 8400-014
13. MALE RUN TEE FITTING PH 64A-66
14. THERMO-COUPLE
15. MANIFOLD OUTLET CONNECTOR PH 68A-6C
16. ORIFICES L.P.
FRONT #1.25mm PO 125 MVORF
REAR #.046” PO 046 MVORF
NATURAL
FRONT #2.05mm PO 205 MVORF
REAR #48 PO 48 MVORF
17. 820 mv. S.I.T. VALVE LP - PE 820-636
NAT - PE 820-637
18. 8”L 3/8”BURNER SUPPLY LINE MF382ALMTUB
(3/4”-3/8” FLARE/3/8” COMP. N&S FITTINGS)
* LOG SET EMBER STOVE BASE (CERAMIC)
