Service level menu (for qualified heating engineers only)
Logamatic SC40 - Technical specifications are subject to change without prior notice.
52
7
7.4 Select system
Manu: Service > Select system
The Select system option allows you to select the basic system and the configuration diagram for
the solar system. There are three basic system options:
– Domestic hot water systems
– Domestic hot water systems with central heating boost facility
– Domestic hot water systems with swimming pool heating
V To switch to the Service level menu: simultaneously press the and buttons.
V Use the rotary selector to select Select system then press to confirm.
V Select the required basic system using the rotary selector .
V Hold down the button and use the rotary selector to select the desired system con-
figuration diagram.
V To save the new setting: release the button.
V To return to the next menu up, press the button.
Within each basic system there are various choices of configuration diagram for the
solar thermal system. The precise designations and layouts of all configuration dia-
grams are detailed in Section 4.4 “Electrical connections”.
Setting range Default setting New setting
Configuration diagrams T1 to T8
Configuration diagrams H1 to H13
Configuration diagrams S1 to S6
H1
Tab. 12
OK
OK
SERVICE
Language
Time
System selection
Settings
Operating mode
>
OK
System selection
Central heating
backup systems
H1
OK
