2 Product Description
The boiler is a low temperature gas boiler.
The boiler consists of the following main components:
– Ignition module (GC124 II only) and adjustable
aquastat
– Boiler jacket and front door
– Boiler block with insulation
– Burner
The ignition module and adjustable aquastat monitor
and control all electrical and operational components of
the boiler.
The boiler jacket prevents energy loss and acts as
soundproofing.
The boiler block transfers the heat generated by the
burner to the heating water. The insulation reduces
energy loss.
Fig. 1 Logano GC124 II/SP gas boiler
1 Boiler front door
2 Aquastat (boiler temperature controller)
3 Ignition module (GC124 II only)
4 Boiler block with insulation
5 Burner
6 Boiler jacket
7 747 000 511-01.0K
6
1
5
3
4
2
GC124 II
GC124 SP
6
1
5
4
2
