Figure 17
• Install Log
o Place front lower edge of log in the
log retention slots at the front of the
burn box.
o Drop log into burn box slots until
they bottom out.
• Close burn chamber door.
• Resume normal stove operation.
Clean Door Glass Airwash - Top and
Bottom (weekly or every 10 to 15 bags)
• Open the door to the burn chamber.
• Using a narrow, firm bristle, nylon
brush, clean along the glass along
both the top and bottom metal
guarding (the entire length of all three
pieces of glass, Figures 18 and 19).
Figure 18
Figure 19
• Vacuum along the same length of
glass, both top and bottom to remove
any ash or other deposits that have
been brushed loose along the length of
glass (Figures 20 and 21).
Figure 20
Figure 21
