BullFrog A7 - Page 55

54
YT-9CEWiringDiagram


Pump1(A1)

Pump2(A3)

Pump3(C1)

Circulationpump/O3(A2)

Voltage
240V


Voltage
240V


Voltage
240V


Voltage
240V

Green/ground
G


Green/ground
G


Green/ground
G


Green/ground
G

Black/lowspeed
K6

Black/lowspeed
K2

Black/lowspeed
K22

Black/lowspeed
K3

Red/highspeed
K1


Red/highspeed
K4


Red/highspeed
K23


White/common
L2

White/common
L2

White/common
L2

White/common
L2

WaterfallPump(C2)

Externallight(C3)

Directoutput(A4)


Voltage
240V


Voltage
240V


Voltage
240V


Green/ground
G


Green/ground
G


Green/ground
G

Black/lowspeed
P34

Black/lowspeed
K24

Black/lowspeed
P28,P30,P32


White/common
L2


White/common
L2


White/common
L2


(yt9)
(Outside North America 50 Hz)
