Adjustment, commissioning
Type 8045
8.2. Operating levels of the device
The device has two operating levels: the Process level and the Con-
figuration level.
Table 1 : Default settings of the device
Function Default value Function Default value
LANGUAGE English OUTPUT
DO3
Hysteresis
UNIT of the
flow rate
l/min. 3–= 0.000
UNIT of the
totalizers
litre 3+= 0.000
K-FACTOR 1.000 Not inverted
OUTPUT
AO1
4 mA= 0.000
time delay = 0
20 mA= 0.000 INPUT DI1 disable
OUTPUT
DO1
pulse FILTER 5, slow
PU= 0.00 litre FREQUENC. 50 Hz
OUTPUT
DO2
Hysteresis CUT-OFF 0.000
2–= 0.000 BACKLIT level 9, acti-
vated for 30 s
2+= 0.000 K-SENSOR Kw= 1.000
Not inverted FLOW-W. W–= 0.000
time delay = 0
W+= 0.000
