Burkert 8045 Quick Start

13
Installation and wiring
Type 8045
Danger
Danger due to the operation of the relay outputs of a UL
device in a wet location.
▶ If a UL device is used in a wet location:
- energize the relay outputs with an alternating voltage of max.
16 Vrms and 22.6 Vpeak.
- or energize the relay outputs with a direct voltage of
max. 35 V DC.
6.8. Electrical connection
Type of connection Through two M20x1,5 cable
glands
Cable specifications
• cable type
• Cross section
• Diameter of each cable:
- if only one cable is used
per cable gland
- if two cables are used per
cable gland
• shielded
• 0,5...1,5 mm
2
- 6...12 mm
- 4 mm, with the supplied
multi-way seal
7. INSTALLATION AND WIRING
7.1. Safety instructions
Danger
Risk of injury due to high pressure in the installation.
Risk of injury due to electrical voltage.
Risk of injury due to high fluid temperatures.
Risk of injury due to the nature of the fluid.
Warning
Risk of injury due to non-conforming installation.
▶ The electrical and fluid installation can only be carried out by
qualified and skilled staff with the appropriate tools.
▶ Install appropriate safety devices (correctly rated fuse and/or
circuit-breaker).
▶ Respect standard NF C 15-100 / IEC 60364.
▶ Observe mounting instructions of the fitting or sensor-fitting.
Risk of injury due to unintentional switch on of power supply
or uncontrolled restarting of the installation.
▶ Take appropriate measures to avoid unintentional activation of
the installation.
▶ Guarantee a set or controlled restarting of the process subse-
quent to any intervention on the device.
