Burkert 8045 Quick Start

12
Technical data
Type 8045
6.7. Electrical data
Operating voltage
• 18...36 V DC,
• filtered and regulated
• oscillation rate: ±5 %
• Connection to main supply: per-
manent (through external SELV
and through LPS power supply)
Specifications of the power
source (not supplied) of the
UL devices
• Limited power source according
to UL / EN 60950-1 standards
• or limited energy circuit
according to UL / EN 61010-1,
Paragraph 9.4
Current consumption
300 mA max. (at 18 V DC)
Transistor output DO1
• type
• function
• frequency
• Electrical data
• duty cycle if f > 2 Hz
• min. pulse duration if f < 2 Hz
• protections
• NPN / PNP (wiring dependent),
open collector
• pulse output (by default), user
configurable
• 0...250 Hz
• 5...36 V DC, 100 mA max.
• 0,5
• 250 ms
• galvanically isolated, and pro-
tected against overvoltages,
polarity reversals and short-circuits
Relay outputs (DO2 and
DO3)
• operating
• electrical data of the load
(non UL recognized devices)
• electrical data of the load
(UL recognized devices)
• max. breaking capacity
• life span
To use the relay outputs in a wet
location, observe the following
safety instruction.
• hysteresis (by default), config-
urable, normally open
• 250 V AC / 3 A or
40 V DC / 3 A (resistive load)
• max. 30 V AC and
42 V peak / 3 A or
max. 60 V DC / 1 A
• 750 VA (resistive load)
• min. 100000 cycles
Current output AO1
• specification
• max. loop impedance
• 4...20 mA, sink or source (wiring
dependent), 22 mA to indicate
a fault
• 1300W at 36 V DC, 1000W at
30 V DC, 700W at 24 V DC,
450W at 18 V DC
Digital input (DI1)
• supply voltage
• input impedance
• min. pulse duration
• protections
• 18...36 V DC
• 15 kW
• 200 ms
• galvanically isolated, and pro-
tected against polarity reversals
and voltage spikes
English
