Instructions on operation in the potentially explosive atmosphere
BVS 16 ATEX E 118 X
1
9
8
10
16
2
12
13
14
15
3
4
5
6
11
7
17
Identicationofexplosionprotection:
Equipment protection level
Temperature class
Dust group
Ignition protection type
Dust
Gas group
Gas
II 3G Ex ec ic IIC T4 Gc
II 3D Ex tc IIIC T135°C Dc
Fig. 2: Type label (example) of a device with ATEX approval
Item Description
1
Manufacturer'slogo
2 Typeidentication,nominalvoltage,nominalpower
3 Device design
(NAMUR/Remote;24VDC/ProbusDP/DeviceNet)
4 Nominalrangeofsupplypressureanddegreeof
protection
5 Ambient temperature range
6 Serial number
7 Order number
8
ExLogo
9 CE marking
10 Other approval logos
11
Manufacturecode
12 ATEX,certicateauthorandcerticatenumber
13 ATEX,identicationoftheexplosionprotection
14 IECEx,certicateauthorandcerticatenumber
15 IECEx,identicationoftheexplosionprotection
16 Barcode (includes order number and serial number)
17 Warning
Tab. 1: Description of the type label data
