Burmester 159 - SPECIFICATIONS; Technical Specifications

45 46
159 MONO POWER AMPLIFIER
Specifications
Technology
Mono amplifier / full bridge, Class
A/B
Width 523 mm
Height 415 mm
Depth 660 mm
Weight approx. 180 kg
Power output
1,400 W (4Ω) according to
IEC62368
Pulse power 2,600 W (4Ω) according to CEA
Power consumption when ON Max. 2.5kW
Power consumption when OFF 0W
Power consumption in standby <0.5W
Continuous current 6.6A
Voltage range (Model 159-120) 100 – 120 V ~, 50/60 Hz
Voltage range (Model 159-240) 220 – 240 V ~, 50/60 Hz
Damping factor 102 – 3,895 in 23 steps
Unweighted signal-to-noise ratio for 1kHz
at 1,200W with 4Ω
>116
Input sensitivity 750 mV
Power bandwidth 410 kHz (-3dB)
Slew rate 160V/µs
THD+N at 1 kHz (50 W / 4 Ω / 22 kHz) 0.0008%
Amplification 39.4 dB
Subject to technical changes without notice
