6
Figure 1A: RSA Packaged Boiler (RSA170 / RSA285)
Boiler
Model
Number
Bare Boiler
Assembly
Minimum Recommended Chimney Sizes
Water
Capacity
(gallons)
Approx.
Shipping
Weight (lb.)
In. x In. x Ft. (height) In. (dia.) x Ft. (height)
RSA170 WV-29-10
8 x 8 x 20
7 x 20 42.6 600
RSA195 WV-29-13A
8 x 20
39.9 630
RSA240 WV-29-16A
8 x 12 x 20
37.3 660
RSA285 WV-29-19A 9 x 20 34.6 690
